FinR, a LysR-type transcriptional regulator involved in sulfur homeostasis with homologs in diverse microorganisms
Momany, C., Nune, M., Brondani, J.C., Afful, D., Neidle, E.To be published.
Experimental Data Snapshot
Starting Model: experimental
View more details
wwPDB Validation   3D Report Full Report
Entity ID: 1 | |||||
---|---|---|---|---|---|
Molecule | Chains | Sequence Length | Organism | Details | Image |
Transcriptional regulator YeiE, LysR family | 209 | Escherichia coli K-12 | Mutation(s): 0  Gene Names: yeiE, b2157, JW2144 | ||
UniProt | |||||
Find proteins for P0ACR4 (Escherichia coli (strain K12)) Explore P0ACR4  Go to UniProtKB:  P0ACR4 | |||||
Entity Groups   | |||||
Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
UniProt Group | P0ACR4 | ||||
Sequence AnnotationsExpand | |||||
|
Ligands 3 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Name / Formula / InChI Key | 2D Diagram | 3D Interactions | |
SO4 Query on SO4 | C [auth A], M [auth B], N [auth B] | SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L | |||
GOL Query on GOL | D [auth A] E [auth A] F [auth A] G [auth A] H [auth A] | GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N | |||
CL Query on CL | P [auth B] | CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M |
Modified Residues 1 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Type | Formula | 2D Diagram | Parent |
CME Query on CME | A, B | L-PEPTIDE LINKING | C5 H11 N O3 S2 | CYS |
Length ( Å ) | Angle ( ˚ ) |
---|---|
a = 71.098 | α = 90 |
b = 71.098 | β = 90 |
c = 196.336 | γ = 90 |
Software Name | Purpose |
---|---|
PHENIX | refinement |
HKL-3000 | data scaling |
HKL-3000 | data reduction |
PHASER | phasing |
Funding Organization | Location | Grant Number |
---|---|---|
National Science Foundation (NSF, United States) | United States | MCB1024108 |
