8R2I

Cryo-EM Structure of native Photosystem II assembly intermediate from Chlamydomonas reinhardtii


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.90 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structure of native photosystem II assembly intermediate from Chlamydomonas reinhardtii .

Fadeeva, M.Klaiman, D.Kandiah, E.Nelson, N.

(2023) Front Plant Sci 14: 1334608-1334608

  • DOI: https://doi.org/10.3389/fpls.2023.1334608
  • Primary Citation of Related Structures:
    8R2I

  • PubMed Abstract:

    Chlamydomonas reinhardtii Photosystem II (PSII) is a dimer consisting of at least 13 nuclear-encoded and four chloroplast-encoded protein subunits that collectively function as a sunlight-driven oxidoreductase. In this study, we present the inaugural structure of a green alga PSII assembly intermediate (pre-PSII-int). This intermediate was isolated from chloroplast membranes of the temperature-sensitive mutant TSP4, cultivated for 14 hours at a non-permissive temperature. The assembly state comprises a monomer containing subunits A, B, C, D, E, F, H, I, K, and two novel assembly factors, Psb1 and Psb2. Psb1 is identified as a novel transmembrane helix located adjacent to PsbE and PsbF (cytochrome b559). The absence of PsbJ, typically found in mature PSII close to this position, indicates that Psb1 functions as an assembly factor. Psb2 is an eukaryotic homolog of the cyanobacterial assembly factor Psb27. The presence of iron, coupled with the absence of Q A , Q B , and the manganese cluster, implies a protective mechanism against photodamage and provides insights into the intricate assembly process.


  • Organizational Affiliation

    The George S. Wise Faculty of Life Sciences, Department of Biochemistry and Molecular Biology, Tel Aviv University, Tel Aviv, Israel.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Photosystem II protein D1327Chlamydomonas reinhardtiiMutation(s): 0
EC: 1.10.3.9
Membrane Entity: Yes
UniProt
Find proteins for P07753 (Chlamydomonas reinhardtii)
Explore P07753
Go to UniProtKB:  P07753
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07753
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Photosystem II CP47 reaction center protein487Chlamydomonas reinhardtiiMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P37255 (Chlamydomonas reinhardtii)
Explore P37255
Go to UniProtKB:  P37255
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP37255
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Photosystem II CP43 reaction center protein423Chlamydomonas reinhardtiiMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P10898 (Chlamydomonas reinhardtii)
Explore P10898
Go to UniProtKB:  P10898
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP10898
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Photosystem II D2 protein350Chlamydomonas reinhardtiiMutation(s): 0
EC: 1.10.3.9
Membrane Entity: Yes
UniProt
Find proteins for P06007 (Chlamydomonas reinhardtii)
Explore P06007
Go to UniProtKB:  P06007
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP06007
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Cytochrome b559 subunit alpha76Chlamydomonas reinhardtiiMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P48268 (Chlamydomonas reinhardtii)
Explore P48268
Go to UniProtKB:  P48268
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP48268
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Cytochrome b559 subunit beta33Chlamydomonas reinhardtiiMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q08363 (Chlamydomonas reinhardtii)
Explore Q08363
Go to UniProtKB:  Q08363
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ08363
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Photosystem II reaction center protein HG [auth H]65Chlamydomonas reinhardtiiMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P22666 (Chlamydomonas reinhardtii)
Explore P22666
Go to UniProtKB:  P22666
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP22666
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Photosystem II reaction center protein IH [auth I]28Chlamydomonas reinhardtiiMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P59763 (Chlamydomonas reinhardtii)
Explore P59763
Go to UniProtKB:  P59763
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP59763
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Photosystem II reaction center protein KI [auth K]37Chlamydomonas reinhardtiiMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P18263 (Chlamydomonas reinhardtii)
Explore P18263
Go to UniProtKB:  P18263
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP18263
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Chain U, Predicted proteinJ [auth 2]101Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for A8I5A0 (Chlamydomonas reinhardtii)
Explore A8I5A0
Go to UniProtKB:  A8I5A0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8I5A0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
Photosystem II reaction center protein Ycf12K [auth 1]32Chlamydomonas reinhardtiiMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P50370 (Chlamydomonas reinhardtii)
Explore P50370
Go to UniProtKB:  P50370
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP50370
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 12 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
DGD
Query on DGD

Download Ideal Coordinates CCD File
EB [auth C]DIGALACTOSYL DIACYL GLYCEROL (DGDG)
C51 H96 O15
LDQFLSUQYHBXSX-HXXRYREZSA-N
CLA
Query on CLA

Download Ideal Coordinates CCD File
AA [auth B]
AB [auth C]
BA [auth B]
CA [auth B]
DA [auth B]
AA [auth B],
AB [auth C],
BA [auth B],
CA [auth B],
DA [auth B],
EA [auth B],
FA [auth B],
GA [auth B],
GB [auth D],
HA [auth B],
JB [auth D],
KB [auth D],
M [auth A],
N [auth A],
OA [auth C],
P [auth A],
PA [auth C],
QA [auth C],
RA [auth C],
S [auth B],
SA [auth C],
T [auth B],
TA [auth C],
U [auth B],
UA [auth C],
V [auth B],
VA [auth C],
W [auth B],
WA [auth C],
X [auth B],
XA [auth C],
Y [auth B],
YA [auth C],
Z [auth B],
ZA [auth C]
CHLOROPHYLL A
C55 H72 Mg N4 O5
ATNHDLDRLWWWCB-AENOIHSZSA-M
PHO
Query on PHO

Download Ideal Coordinates CCD File
HB [auth D],
O [auth A]
PHEOPHYTIN A
C55 H74 N4 O5
CQIKWXUXPNUNDV-RCBXBCQGSA-N
LMG
Query on LMG

Download Ideal Coordinates CCD File
KA [auth B],
QB [auth H]
1,2-DISTEAROYL-MONOGALACTOSYL-DIGLYCERIDE
C45 H86 O10
DCLTVZLYPPIIID-CVELTQQQSA-N
PL9
Query on PL9

Download Ideal Coordinates CCD File
MB [auth D]2,3-DIMETHYL-5-(3,7,11,15,19,23,27,31,35-NONAMETHYL-2,6,10,14,18,22,26,30,34-HEXATRIACONTANONAENYL-2,5-CYCLOHEXADIENE-1,4-DIONE-2,3-DIMETHYL-5-SOLANESYL-1,4-BENZOQUINONE
C53 H80 O2
FKUYMLZIRPABFK-UHFFFAOYSA-N
LHG
Query on LHG

Download Ideal Coordinates CCD File
NA [auth B]1,2-DIPALMITOYL-PHOSPHATIDYL-GLYCEROLE
C38 H75 O10 P
BIABMEZBCHDPBV-MPQUPPDSSA-N
HEM
Query on HEM

Download Ideal Coordinates CCD File
OB [auth E]PROTOPORPHYRIN IX CONTAINING FE
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
BCR
Query on BCR

Download Ideal Coordinates CCD File
BB [auth C]
CB [auth C]
DB [auth C]
IA [auth B]
JA [auth B]
BB [auth C],
CB [auth C],
DB [auth C],
IA [auth B],
JA [auth B],
LB [auth D],
PB [auth H],
Q [auth A]
BETA-CAROTENE
C40 H56
OENHQHLEOONYIE-JLTXGRSLSA-N
LMT
Query on LMT

Download Ideal Coordinates CCD File
LA [auth B],
MA [auth B]
DODECYL-BETA-D-MALTOSIDE
C24 H46 O11
NLEBIOOXCVAHBD-QKMCSOCLSA-N
BOG
Query on BOG

Download Ideal Coordinates CCD File
FB [auth C],
NB [auth D],
R [auth A]
octyl beta-D-glucopyranoside
C14 H28 O6
HEGSGKPQLMEBJL-RKQHYHRCSA-N
BCT
Query on BCT

Download Ideal Coordinates CCD File
IB [auth D]BICARBONATE ION
C H O3
BVKZGUZCCUSVTD-UHFFFAOYSA-M
FE2
Query on FE2

Download Ideal Coordinates CCD File
L [auth A]FE (II) ION
Fe
CWYNVVGOOAEACU-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.90 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION4.0.0

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Israel Science FoundationIsrael199/21

Revision History  (Full details and data files)

  • Version 1.0: 2024-01-31
    Type: Initial release
  • Version 1.1: 2024-02-21
    Changes: Database references
