8OHZ

Yeast 20S proteasome in complex with a photoswitchable cepafungin derivative (transCep1)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.180
  • R-Value Observed: 0.182

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Optical Control of Proteasomal Protein Degradation with a Photoswitchable Lipopeptide.

Morstein, J.Amatuni, A.Shuster, A.Kuttenlochner, W.Ko, T.Abegg, D.Groll, M.Adibekian, A.Renata, H.Trauner, D.H.

(2024) Angew Chem Int Ed Engl 63: e202314791-e202314791

  • DOI: https://doi.org/10.1002/anie.202314791
  • Primary Citation of Related Structures:
    8OHZ, 8OI1

  • PubMed Abstract:

    Photolipids have emerged as attractive tools for the optical control of lipid functions. They often contain an azobenzene photoswitch that imparts a cis double-bond upon irradiation. Herein, we present the application of photoswitching to a lipidated natural product, the potent proteasome inhibitor cepafungin I. Several azobenzene-containing lipids were attached to the cyclopeptide core, yielding photoswitchable derivatives. Most notably, PhotoCep4 exhibited a 10-fold higher cellular potency in its light-induced cis-form, matching the potency of natural cepafungin I. The length of the photolipid tail and distal positioning of the azobenzene photoswitch with respect to the macrocycle is critical for this activity. In a proteome-wide experiment, light-triggered PhotoCep4 modulation showed high overlap with constitutively active cepafungin I. The mode of action was studied using crystallography and revealed an identical binding of the cyclopeptide in comparison to cepafungin I, suggesting that differences in their cellular activity originate from switching the tail structure. The photopharmacological approach described herein could be applicable to many other natural products as lipid conjugation is common and often necessary for potent activity. Such lipids are often introduced late in synthetic routes, enabling facile chemical modifications.


  • Organizational Affiliation

    Department of Cellular and Molecular Pharmacology and Howard Hughes Medical Institute, University of California, San Francisco, CA-94158, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-2
A, O
250Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P23639 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P23639
Go to UniProtKB:  P23639
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP23639
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-3
B, P
258Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P23638 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P23638
Go to UniProtKB:  P23638
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP23638
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-4
C, Q
254Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P40303 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P40303
Go to UniProtKB:  P40303
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP40303
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-5
D, R
260Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P32379 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P32379
Go to UniProtKB:  P32379
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP32379
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-6
E, S
234Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P40302 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P40302
Go to UniProtKB:  P40302
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP40302
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Probable proteasome subunit alpha type-7
F, T
288Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P21242 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P21242
Go to UniProtKB:  P21242
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP21242
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-1
G, U
252Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P21243 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P21243
Go to UniProtKB:  P21243
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP21243
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-2
H, V
232Saccharomyces cerevisiaeMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for P25043 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P25043
Go to UniProtKB:  P25043
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25043
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-3
I, W
205Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P25451 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P25451
Go to UniProtKB:  P25451
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25451
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-4
J, X
198Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P22141 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P22141
Go to UniProtKB:  P22141
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP22141
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-5
K, Y
212Saccharomyces cerevisiaeMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for P30656 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P30656
Go to UniProtKB:  P30656
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP30656
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-6
L, Z
222Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P23724 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P23724
Go to UniProtKB:  P23724
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP23724
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-7AA [auth a],
M
246Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P30657 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P30657
Go to UniProtKB:  P30657
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP30657
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-1BA [auth b],
N
196Saccharomyces cerevisiaeMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for P38624 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P38624
Go to UniProtKB:  P38624
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP38624
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
VOT (Subject of Investigation/LOI)
Query on VOT

Download Ideal Coordinates CCD File
DA [auth H],
GA [auth K],
KA [auth V],
MA [auth Y]
(2~{S},3~{R})-2-[2-[4-[2-(4-ethylphenyl)hydrazinyl]phenyl]ethanoylamino]-~{N}-[(5~{S},8~{S},10~{S})-5-methyl-10-oxidanyl-2,7-bis(oxidanylidene)-1,6-diazacyclododec-8-yl]-3-oxidanyl-butanamide
C31 H44 N6 O6
RFGUMPPDEDFOAF-HXNWBPOKSA-N
CL
Query on CL

Download Ideal Coordinates CCD File
JA [auth N],
PA [auth b]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
MG
Query on MG

Download Ideal Coordinates CCD File
CA [auth G]
EA [auth I]
FA [auth J]
HA [auth K]
IA [auth N]
CA [auth G],
EA [auth I],
FA [auth J],
HA [auth K],
IA [auth N],
LA [auth V],
NA [auth Y],
OA [auth Z]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.180
  • R-Value Observed: 0.182
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 135.51α = 90
b = 300.79β = 113.41
c = 144.77γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XSCALEdata scaling
REFMACphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research Foundation (DFG)GermanyGR 1861/10-3

Revision History  (Full details and data files)

  • Version 1.0: 2023-12-27
    Type: Initial release
  • Version 1.1: 2024-02-21
    Changes: Database references
