8KFJ | pdb_00008kfj

Crystal structure of sperm whale myoglobin (F46L/H64A mutant) reconstituted with manganese porphycene

PDB DOI: https://doi.org/10.2210/pdb8KFJ/pdb

Classification: OXYGEN STORAGE
Organism(s): Physeter macrocephalus
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2023-08-15 Released: 2024-08-21
Deposition Author(s): Mizohata, E., Oohora, K., Hayashi, T.
Funding Organization(s): Japan Society for the Promotion of Science (JSPS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.212 (Depositor), 0.219 (DCC)
R-Value Work:
0.179 (Depositor), 0.189 (DCC)
R-Value Observed:
0.180 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Rational design of an artificial ethylbenzene hydroxylase using a molecular dynamics simulation to enhance enantioselectivity.

Oohora, K., Kagawa, Y., Nishiura, T., Mizohata, E., Schwaneberg, U., Hayashi, T.

(2024) Chem Lett 53

DOI: https://doi.org/10.1093/chemle/upad042

Macromolecule Content

Total Structure Weight: 41.1 kDa
Atom Count: 2,958
Modeled Residue Count: 320
Deposited Residue Count: 340
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Myoglobin	A, B	170	Physeter macrocephalus	Mutation(s): 2 Gene Names: MB EC: 1.11.1 (UniProt), 1.7 (UniProt)
UniProt
Find proteins for P02185 (Physeter macrocephalus) Explore P02185 Go to UniProtKB: P02185
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P02185
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
HNN (Subject of Investigation/LOI) Query on HNN Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain K [auth B] MOL2 format, chain C [auth A] MOL2 format, chain K [auth B] mmCIF format, chain C [auth A] mmCIF format, chain K [auth B]	C [auth A], K [auth B]	PORPHYCENE CONTAINING MN C₃₄ H₃₆ Mn N₄ O₄ YIZMGGNKFAWJJG-BWTHIWHLSA-L		Interactions Focus chain C [auth A] Focus chain K [auth B] Interactions & Density Focus chain C [auth A] Focus chain K [auth B]
SO4 (Subject of Investigation/LOI) Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain I [auth A] SDF format, chain L [auth B] SDF format, chain M [auth B] SDF format, chain N [auth B] SDF format, chain O [auth B] SDF format, chain P [auth B] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain H [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain I [auth A] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] MOL2 format, chain P [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain H [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain I [auth A] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B] mmCIF format, chain P [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain H [auth A]	D [auth A] E [auth A] F [auth A] G [auth A] H [auth A] D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], L [auth B], M [auth B], N [auth B], O [auth B], P [auth B], Q [auth B], R [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B]
CL (Subject of Investigation/LOI) Query on CL Download:Ideal Coordinates CCD File SDF format, chain J [auth A] MOL2 format, chain J [auth A] mmCIF format, chain J [auth A]	J [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain J [auth A] Interactions & Density Focus chain J [auth A]
