8JSB | pdb_00008jsb

Antibody scFv against the Matrix protein 2 of influenza virus

PDB DOI: https://doi.org/10.2210/pdb8JSB/pdb

Classification: ANTIVIRAL PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2023-06-19 Released: 2024-05-29
Deposition Author(s): Kumar, U., Gaur, V., Salunke, D.M.
Funding Organization(s): Department of Biotechnology (DBT, India)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.03 Å
R-Value Free:
0.267 (Depositor), 0.270 (DCC)
R-Value Work:
0.223 (Depositor), 0.220 (DCC)
R-Value Observed:
0.225 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Antibody scFv against the Matrix protein 2 of influenza virus

Kumar, U., Gaur, V., Salunke, D.M.

To be published.

Macromolecule Content

Total Structure Weight: 108.14 kDa
Atom Count: 6,657
Modeled Residue Count: 888
Deposited Residue Count: 1,012
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
single chain variable fragment	A, B, C, D	253	Homo sapiens	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.03 Å
R-Value Free: 0.267 (Depositor), 0.270 (DCC)
R-Value Work: 0.223 (Depositor), 0.220 (DCC)
R-Value Observed: 0.225 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 101.104	α = 90
b = 98.391	β = 94.33
c = 94.563	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
autoPROC	data reduction
autoPROC	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2024-05-29

Deposition Author(s):

Funding Organization	Location	Grant Number
Department of Biotechnology (DBT, India)	India	--

Revision History (Full details and data files)

Version 1.0: 2024-05-29
Type: Initial release
Version 1.1: 2024-10-16
Changes: Structure summary
