8J9Q

Crystal structure of UBR box of UBR4 apo


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.18 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.219
  • R-Value Observed: 0.222

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Insights into the recognition mechanism in the UBR box of UBR4 for its specific substrates.

Jeong, D.E.Lee, H.S.Ku, B.Kim, C.H.Kim, S.J.Shin, H.C.

(2023) Commun Biol 6: 1214-1214

  • DOI: https://doi.org/10.1038/s42003-023-05602-7
  • Primary Citation of Related Structures:
    8J9Q, 8J9R

  • PubMed Abstract:

    The N-end rule pathway is a proteolytic system involving the destabilization of N-terminal amino acids, known as N-degrons, which are recognized by N-recognins. Dysregulation of the N-end rule pathway results in the accumulation of undesired proteins, causing various diseases. The E3 ligases of the UBR subfamily recognize and degrade N-degrons through the ubiquitin-proteasome system. Herein, we investigated UBR4, which has a distinct mechanism for recognizing type-2 N-degrons. Structural analysis revealed that the UBR box of UBR4 differs from other UBR boxes in the N-degron binding sites. It recognizes type-2 N-terminal amino acids containing an aromatic ring and type-1 N-terminal arginine through two phenylalanines on its hydrophobic surface. We also characterized the binding mechanism for the second ligand residue. This is the report on the structural basis underlying the recognition of type-2 N-degrons by the UBR box with implications for understanding the N-end rule pathway.


  • Organizational Affiliation

    Critical Disease Diagnostics Convergence Research Center, Korea Research Institute of Bioscience and Biotechnology (KRIBB), Daejeon, 34141, Republic of Korea.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
E3 ubiquitin-protein ligase UBR4
A, B, C
73Homo sapiensMutation(s): 0
Gene Names: UBR4KIAA0462KIAA1307RBAF600ZUBR1
EC: 2.3.2.27
UniProt & NIH Common Fund Data Resources
Find proteins for Q5T4S7 (Homo sapiens)
Explore Q5T4S7
Go to UniProtKB:  Q5T4S7
PHAROS:  Q5T4S7
GTEx:  ENSG00000127481
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5T4S7
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.18 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.219
  • R-Value Observed: 0.222
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 43.67α = 90
b = 80.75β = 90
c = 81.32γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Other governmentKorea, Republic OfCRC22021-700
Other governmentKorea, Republic OfKGM9952314
Other governmentKorea, Republic Of2021M3A9G8025599

Revision History  (Full details and data files)

  • Version 1.0: 2023-12-06
    Type: Initial release
  • Version 1.1: 2023-12-13
    Changes: Database references
