8GQF | pdb_00008gqf

Crystal structure of Thiolase

• PDB DOI: https://doi.org/10.2210/pdb8GQF/pdb

• Classification: TRANSFERASE
• Organism(s): Pseudomonas aeruginosa PAO1
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2022-08-30 Released: 2024-03-13
• Deposition Author(s): Hong, J., Son, H.F., Kim, K.J.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:
  0.220 (Depositor), 0.230 (DCC)
• R-Value Work:
  0.181 (Depositor), 0.190 (DCC)
• R-Value Observed:
  0.183 (Depositor)

Literature

Structure of thiolase from Pseudomonas aeruginosa PAO1

Hong, J., Son, H.F., Kim, K.J.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 170.24 kDa
• Atom Count: 11,805
• Modeled Residue Count: 1,513
• Deposited Residue Count: 1,628
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Thiolase	A, B, C, D	407	Pseudomonas aeruginosa PAO1	Mutation(s): 0
UniProt
Find proteins for Q9HZQ7 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore Q9HZQ7  Go to UniProtKB:  Q9HZQ7

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	E [auth A], F [auth A], G [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:  0.220 (Depositor), 0.230 (DCC)
• R-Value Work:  0.181 (Depositor), 0.190 (DCC)
• R-Value Observed: 0.183 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 50.562	α = 90.01
b = 82.266	β = 75
c = 97.739	γ = 89.95

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data scaling
PDB_EXTRACT	data extraction
HKL-2000	data reduction
REFMAC	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2024-03-13
Deposition Author(s): Hong, J., Son, H.F., Kim, K.J.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2024-03-13
  Type: Initial release
