8G6F

Structure of the Plasmodium falciparum 20S proteasome beta-6 A117D mutant complexed with inhibitor WLW-vs


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.58 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structures revealing mechanisms of resistance and collateral sensitivity of Plasmodium falciparum to proteasome inhibitors.

Hsu, H.C.Li, D.Zhan, W.Ye, J.Liu, Y.J.Leung, A.Qin, J.Crespo, B.Gamo, F.J.Zhang, H.Cui, L.Roth, A.Kirkman, L.A.Li, H.Lin, G.

(2023) Nat Commun 14: 8302-8302

  • DOI: https://doi.org/10.1038/s41467-023-44077-2
  • Primary Citation of Related Structures:
    8G6E, 8G6F, 8UD9

  • PubMed Abstract:

    The proteasome of the malaria parasite Plasmodium falciparum (Pf20S) is an advantageous drug target because its inhibition kills P. falciparum in multiple stages of its life cycle and synergizes with artemisinins. We recently developed a macrocyclic peptide, TDI-8304, that is highly selective for Pf20S over human proteasomes and is potent in vitro and in vivo against P. falciparum. A mutation in the Pf20S β6 subunit, A117D, confers resistance to TDI-8304, yet enhances both enzyme inhibition and anti-parasite activity of a tripeptide vinyl sulfone β2 inhibitor, WLW-vs. Here we present the high-resolution cryo-EM structures of Pf20S with TDI-8304, of human constitutive proteasome with TDI-8304, and of Pf20Sβ6 A117D with WLW-vs that give insights into the species selectivity of TDI-8304, resistance to it, and the collateral sensitivity associated with resistance, including that TDI-8304 binds β2 and β5 in wild type Pf20S as well as WLW-vs binds β2 and β5 in Pf20Sβ6 A117D . We further show that TDI-8304 kills P. falciparum as quickly as chloroquine and artemisinin and is active against P. cynomolgi at the liver stage. This increases interest in using these structures to facilitate the development of Pf20S inhibitors that target multiple proteasome subunits and limit the emergence of resistance.


  • Organizational Affiliation

    Department of Structural Biology, Van Andel Institute, 333 Bostwick Ave NE, Grand Rapids, MI, 49503, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-6
A, O
260Plasmodium falciparum Dd2Mutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for Q8IAR3 (Plasmodium falciparum (isolate 3D7))
Explore Q8IAR3
Go to UniProtKB:  Q8IAR3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8IAR3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-2
B, P
235Plasmodium falciparum Dd2Mutation(s): 0
UniProt
Find proteins for C6KST3 (Plasmodium falciparum (isolate 3D7))
Explore C6KST3
Go to UniProtKB:  C6KST3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC6KST3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-3
C, Q
246Plasmodium falciparum Dd2Mutation(s): 0
UniProt
Find proteins for Q8IDG3 (Plasmodium falciparum (isolate 3D7))
Explore Q8IDG3
Go to UniProtKB:  Q8IDG3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8IDG3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-4
D, R
241Plasmodium falciparum Dd2Mutation(s): 0
UniProt
Find proteins for Q8IDG2 (Plasmodium falciparum (isolate 3D7))
Explore Q8IDG2
Go to UniProtKB:  Q8IDG2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8IDG2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-5
E, S
256Plasmodium falciparum Dd2Mutation(s): 0
UniProt
Find proteins for Q8IBI3 (Plasmodium falciparum (isolate 3D7))
Explore Q8IBI3
Go to UniProtKB:  Q8IBI3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8IBI3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-1
F, T
254Plasmodium falciparum Dd2Mutation(s): 0
UniProt
Find proteins for Q8IK90 (Plasmodium falciparum (isolate 3D7))
Explore Q8IK90
Go to UniProtKB:  Q8IK90
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8IK90
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-3
G, U
252Plasmodium falciparum Dd2Mutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for O77396 (Plasmodium falciparum (isolate 3D7))
Explore O77396
Go to UniProtKB:  O77396
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO77396
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome endopeptidase complex
H, V
252Plasmodium falciparum Dd2Mutation(s): 0
UniProt
Find proteins for Q8I0U7 (Plasmodium falciparum (isolate 3D7))
Explore Q8I0U7
Go to UniProtKB:  Q8I0U7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8I0U7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta-2
I, W
229Plasmodium falciparum Dd2Mutation(s): 0
UniProt
Find proteins for Q8I6T3 (Plasmodium falciparum (isolate 3D7))
Explore Q8I6T3
Go to UniProtKB:  Q8I6T3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8I6T3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta-3
J, X
218Plasmodium falciparum Dd2Mutation(s): 0
UniProt
Find proteins for Q8I261 (Plasmodium falciparum (isolate 3D7))
Explore Q8I261
Go to UniProtKB:  Q8I261
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8I261
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta-4
K, Y
195Plasmodium falciparum Dd2Mutation(s): 0
UniProt
Find proteins for Q8IKC9 (Plasmodium falciparum (isolate 3D7))
Explore Q8IKC9
Go to UniProtKB:  Q8IKC9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8IKC9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta-5
L, Z
211Plasmodium falciparum Dd2Mutation(s): 0
UniProt
Find proteins for Q8IJT1 (Plasmodium falciparum (isolate 3D7))
Explore Q8IJT1
Go to UniProtKB:  Q8IJT1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8IJT1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta-6AA [auth a],
M
240Plasmodium falciparum Dd2Mutation(s): 1
UniProt
Find proteins for A0A5K1K7U1 (Plasmodium falciparum (isolate 3D7))
Explore A0A5K1K7U1
Go to UniProtKB:  A0A5K1K7U1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A5K1K7U1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta-7BA [auth b],
N
265Plasmodium falciparum Dd2Mutation(s): 0
UniProt
Find proteins for Q7K6A9 (Plasmodium falciparum (isolate 3D7))
Explore Q7K6A9
Go to UniProtKB:  Q7K6A9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7K6A9
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.58 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC3.3.2
MODEL REFINEMENTPHENIX1.20.1-4487

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAI143714

Revision History  (Full details and data files)

  • Version 1.0: 2023-12-20
    Type: Initial release
  • Version 1.1: 2024-01-03
    Changes: Database references
