8G5K

Cryo-EM structure of the Wedge Alignment Complex (VIII) of Human Mitochondrial DNA Polymerase Gamma


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.90 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structural basis for DNA proofreading.

Buchel, G.Nayak, A.R.Herbine, K.Sarfallah, A.Sokolova, V.O.Zamudio-Ochoa, A.Temiakov, D.

(2023) Nat Commun 14: 8501-8501

  • DOI: https://doi.org/10.1038/s41467-023-44198-8
  • Primary Citation of Related Structures:
    8G5I, 8G5J, 8G5K, 8G5L, 8G5M, 8G5N, 8G5O, 8G5P, 8T7E

  • PubMed Abstract:

    DNA polymerase (DNAP) can correct errors in DNA during replication by proofreading, a process critical for cell viability. However, the mechanism by which an erroneously incorporated base translocates from the polymerase to the exonuclease site and the corrected DNA terminus returns has remained elusive. Here, we present an ensemble of nine high-resolution structures representing human mitochondrial DNA polymerase Gamma, Polγ, captured during consecutive proofreading steps. The structures reveal key events, including mismatched base recognition, its dissociation from the polymerase site, forward translocation of DNAP, alterations in DNA trajectory, repositioning and refolding of elements for primer separation, DNAP backtracking, and displacement of the mismatched base into the exonuclease site. Altogether, our findings suggest a conserved 'bolt-action' mechanism of proofreading based on iterative cycles of DNAP translocation without dissociation from the DNA, facilitating primer transfer between catalytic sites. Functional assays and mutagenesis corroborate this mechanism, connecting pathogenic mutations to crucial structural elements in proofreading steps.


  • Organizational Affiliation

    Department of Biochemistry and Molecular Biology, Thomas Jefferson University, 1020 Locust St, Philadelphia, PA, 19107, USA.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA polymerase subunit gamma-11,239Homo sapiensMutation(s): 0
Gene Names: POLGMDP1POLG1POLGA
EC: 2.7.7.7
UniProt & NIH Common Fund Data Resources
Find proteins for P54098 (Homo sapiens)
Explore P54098
Go to UniProtKB:  P54098
PHAROS:  P54098
GTEx:  ENSG00000140521
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP54098
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA polymerase subunit gamma-2, mitochondrial
B, C
485Homo sapiensMutation(s): 0
Gene Names: POLG2MTPOLB
EC: 2.7.7.7
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UHN1 (Homo sapiens)
Explore Q9UHN1
Go to UniProtKB:  Q9UHN1
PHAROS:  Q9UHN1
GTEx:  ENSG00000256525
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9UHN1
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains LengthOrganismImage
Mismatched Primer DNAD [auth P]20synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains LengthOrganismImage
Template DNAE [auth T]26synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.90 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC4.0
MODEL REFINEMENTPHENIX1.21rc1_4985

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesNIH GM131832

Revision History  (Full details and data files)

  • Version 1.0: 2024-01-10
    Type: Initial release
