8G1I | pdb_00008g1i

SpCas9 with sgRNA and target DNA

PDB DOI: https://doi.org/10.2210/pdb8G1I/pdb
EM Map EMD-29671: EMDB EMDataResource
NAKB: 8G1I

Classification: HYDROLASE
Organism(s): Streptococcus pyogenes, Renilla reniformis
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2023-02-02 Released: 2023-05-17
Deposition Author(s): Korolev, S., Gagnon, K.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.12 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8G1I

This is version 1.1 of the entry. See complete history.

Literature

SpCas9 with sgRNA and target DNA

Korolev, S., Gagnon, K.

To be published.

Macromolecule Content

Total Structure Weight: 216.94 kDa
Atom Count: 13,613
Modeled Residue Count: 1,440
Deposited Residue Count: 1,562
Unique protein chains: 1
Unique nucleic acid chains: 3

Macromolecules

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
CRISPR-associated endonuclease Cas9/Csn1	B [auth A]	1,384	Streptococcus pyogenes	Mutation(s): 0 Gene Names: cas9, csn1, SPy_1046 EC: 3.1
UniProt
Find proteins for Q99ZW2 (Streptococcus pyogenes serotype M1) Explore Q99ZW2 Go to UniProtKB: Q99ZW2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q99ZW2
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by:

(by identity cutoff)

Molecule	Chains	Length	Organism	Image
Entity ID: 1
sgRNA	A [auth B]	98	Streptococcus pyogenes
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by:

(by identity cutoff)

Molecule	Chains	Length	Organism	Image
Entity ID: 3
DNA E2_TS	C	40	Renilla reniformis
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by:

(by identity cutoff)

Molecule	Chains	Length	Organism	Image
Entity ID: 4
DNA E2_NTS	D	40	Renilla reniformis
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.12 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.20.1

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-05-17

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	--

Revision History (Full details and data files)

Version 1.0: 2023-05-17
Type: Initial release
Version 1.1: 2024-06-19
Changes: Data collection
