8EY9 | pdb_00008ey9

Structure of Arabidopsis fatty acid amide hydrolase mutant S305A in complex with 9-hydroxy-10,12-octadecadienoyl-ethanolamide

PDB DOI: https://doi.org/10.2210/pdb8EY9/pdb

Classification: HYDROLASE
Organism(s): Arabidopsis thaliana
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2022-10-26 Released: 2024-05-29
Deposition Author(s): Aziz, M., Wang, X., Gaguancela, O.A., Chapman, K.D.
Funding Organization(s): National Science Foundation (NSF, United States)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.59 Å
R-Value Free:
0.305 (Depositor), 0.306 (DCC)
R-Value Work:
0.269 (Depositor), 0.271 (DCC)
R-Value Observed:
0.270 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8EY9

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Structural interactions explain the versatility of FAAH in the hydrolysis of plant and microbial acyl amide signals

Aziz, M., Wang, X., Gaguancela, O.A., Chapman, K.D.

To be published.

Macromolecule Content

Total Structure Weight: 836.79 kDa
Atom Count: 55,530
Modeled Residue Count: 7,242
Deposited Residue Count: 7,632
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fatty acid amide hydrolase	A, B, C, D, E A, B, C, D, E, F, G, H, I, J, K, L	636	Arabidopsis thaliana	Mutation(s): 1 Gene Names: FAAH, At5g64440, T12B11.3 EC: 3.5.1.99
UniProt
Find proteins for Q7XJJ7 (Arabidopsis thaliana) Explore Q7XJJ7 Go to UniProtKB: Q7XJJ7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q7XJJ7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
X4X (Subject of Investigation/LOI) Query on X4X Download:Ideal Coordinates CCD File SDF format, chain R [auth I] SDF format, chain Q [auth H] SDF format, chain P [auth G] SDF format, chain O [auth F] SDF format, chain N [auth E] SDF format, chain M [auth B] MOL2 format, chain R [auth I] MOL2 format, chain Q [auth H] MOL2 format, chain P [auth G] MOL2 format, chain O [auth F] MOL2 format, chain N [auth E] MOL2 format, chain M [auth B] mmCIF format, chain R [auth I] mmCIF format, chain Q [auth H] mmCIF format, chain P [auth G] mmCIF format, chain O [auth F] mmCIF format, chain N [auth E] mmCIF format, chain M [auth B]	M [auth B] N [auth E] O [auth F] P [auth G] Q [auth H] M [auth B], N [auth E], O [auth F], P [auth G], Q [auth H], R [auth I]	(9R,10E,12Z)-9-hydroxy-N-(2-hydroxyethyl)octadeca-10,12-dienamide C₂₀ H₃₇ N O₃ VYCHZJQSKAOAAT-HGKNAVPSSA-N		Interactions Focus chain M [auth B] Focus chain N [auth E] Focus chain O [auth F] Focus chain P [auth G] Focus chain Q [auth H] Focus chain R [auth I] Interactions & Density Focus chain M [auth B] Focus chain N [auth E] Focus chain O [auth F] Focus chain P [auth G] Focus chain Q [auth H] Focus chain R [auth I]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.59 Å
R-Value Free: 0.305 (Depositor), 0.306 (DCC)
R-Value Work: 0.269 (Depositor), 0.271 (DCC)
R-Value Observed: 0.270 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 222.906	α = 90
b = 82.908	β = 109.13
c = 271.784	γ = 90

Software Package:

Software Name	Purpose
Aimless	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-05-29

Deposition Author(s):

Gaguancela, O.A.

Funding Organization	Location	Grant Number
National Science Foundation (NSF, United States)	United States	--

Revision History (Full details and data files)

Version 1.0: 2024-05-29
Type: Initial release
Version 1.1: 2026-03-04
Changes: Refinement description, Structure summary
