8EBT

XPA repositioning Core7 of TFIIH relative to XPC-DNA lesion (Cy5)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.90 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Lesion recognition by XPC, TFIIH and XPA in DNA excision repair.

Kim, J.Li, C.L.Chen, X.Cui, Y.Golebiowski, F.M.Wang, H.Hanaoka, F.Sugasawa, K.Yang, W.

(2023) Nature 617: 170-175

  • DOI: https://doi.org/10.1038/s41586-023-05959-z
  • Primary Citation of Related Structures:
    8EBS, 8EBT, 8EBU, 8EBV, 8EBW, 8EBX, 8EBY

  • PubMed Abstract:

    Nucleotide excision repair removes DNA lesions caused by ultraviolet light, cisplatin-like compounds and bulky adducts 1 . After initial recognition by XPC in global genome repair or a stalled RNA polymerase in transcription-coupled repair, damaged DNA is transferred to the seven-subunit TFIIH core complex (Core7) for verification and dual incisions by the XPF and XPG nucleases 2 . Structures capturing lesion recognition by the yeast XPC homologue Rad4 and TFIIH in transcription initiation or DNA repair have been separately reported 3-7 . How two different lesion recognition pathways converge and how the XPB and XPD helicases of Core7 move the DNA lesion for verification are unclear. Here we report on structures revealing DNA lesion recognition by human XPC and DNA lesion hand-off from XPC to Core7 and XPA. XPA, which binds between XPB and XPD, kinks the DNA duplex and shifts XPC and the DNA lesion by nearly a helical turn relative to Core7. The DNA lesion is thus positioned outside of Core7, as would occur with RNA polymerase. XPB and XPD, which track the lesion-containing strand but translocate DNA in opposite directions, push and pull the lesion-containing strand into XPD for verification.


  • Organizational Affiliation

    Laboratory of Molecular Biology, NIDDK, National Institutes of Health, Bethesda, MD, USA.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
General transcription and DNA repair factor IIH helicase subunit XPB603Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P19447 (Homo sapiens)
Explore P19447
Go to UniProtKB:  P19447
PHAROS:  P19447
GTEx:  ENSG00000163161
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP19447
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
General transcription and DNA repair factor IIH helicase subunit XPD730Homo sapiensMutation(s): 0
Gene Names: ERCC2XPDXPDC
EC: 3.6.4.12
UniProt & NIH Common Fund Data Resources
Find proteins for P18074 (Homo sapiens)
Explore P18074
Go to UniProtKB:  P18074
PHAROS:  P18074
GTEx:  ENSG00000104884
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP18074
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
General transcription factor IIH subunit 1438Homo sapiensMutation(s): 0
Gene Names: GTF2H1BTF2
UniProt & NIH Common Fund Data Resources
Find proteins for P32780 (Homo sapiens)
Explore P32780
Go to UniProtKB:  P32780
PHAROS:  P32780
GTEx:  ENSG00000110768
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP32780
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
General transcription factor IIH subunit 4446Homo sapiensMutation(s): 0
Gene Names: GTF2H4
UniProt & NIH Common Fund Data Resources
Find proteins for Q92759 (Homo sapiens)
Explore Q92759
Go to UniProtKB:  Q92759
PHAROS:  Q92759
GTEx:  ENSG00000213780
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ92759
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
General transcription factor IIH subunit 2380Homo sapiensMutation(s): 0
Gene Names: GTF2H2BTF2P44
UniProt & NIH Common Fund Data Resources
Find proteins for Q13888 (Homo sapiens)
Explore Q13888
Go to UniProtKB:  Q13888
GTEx:  ENSG00000145736
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ13888
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
General transcription factor IIH subunit 3284Homo sapiensMutation(s): 0
Gene Names: GTF2H3
UniProt & NIH Common Fund Data Resources
Find proteins for Q13889 (Homo sapiens)
Explore Q13889
Go to UniProtKB:  Q13889
PHAROS:  Q13889
GTEx:  ENSG00000111358
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ13889
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
General transcription factor IIH subunit 566Homo sapiensMutation(s): 0
Gene Names: GTF2H5C6orf175TTDA
UniProt & NIH Common Fund Data Resources
Find proteins for Q6ZYL4 (Homo sapiens)
Explore Q6ZYL4
Go to UniProtKB:  Q6ZYL4
PHAROS:  Q6ZYL4
GTEx:  ENSG00000272047
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6ZYL4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
DNA repair protein complementing XP-C cells274Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q01831 (Homo sapiens)
Explore Q01831
Go to UniProtKB:  Q01831
PHAROS:  Q01831
GTEx:  ENSG00000154767
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ01831
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Centrin-2I [auth J]70Homo sapiensMutation(s): 0
Gene Names: CETN2CALTCEN2
UniProt & NIH Common Fund Data Resources
Find proteins for P41208 (Homo sapiens)
Explore P41208
Go to UniProtKB:  P41208
PHAROS:  P41208
GTEx:  ENSG00000147400
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP41208
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
DNA repair protein complementing XP-A cellsJ [auth K]172Homo sapiensMutation(s): 0
Gene Names: XPAXPAC
UniProt & NIH Common Fund Data Resources
Find proteins for P23025 (Homo sapiens)
Explore P23025
Go to UniProtKB:  P23025
PHAROS:  P23025
GTEx:  ENSG00000136936
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP23025
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains LengthOrganismImage
DNA (Cy5)K [auth L]44synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains LengthOrganismImage
DNAL [auth M]45synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SF4
Query on SF4

Download Ideal Coordinates CCD File
M [auth B]IRON/SULFUR CLUSTER
Fe4 S4
LJBDFODJNLIPKO-UHFFFAOYSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
N [auth E]
O [auth E]
P [auth E]
Q [auth F]
R [auth F]
N [auth E],
O [auth E],
P [auth E],
Q [auth F],
R [auth F],
U [auth K]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
S [auth J],
T [auth J]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.90 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION
MODEL REFINEMENTPHENIX

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of Diabetes and Digestive and Kidney Disease (NIH/NIDDK)United StatesDK075037
Japan Society for the Promotion of Science (JSPS)JapanJP16H06307
Japan Society for the Promotion of Science (JSPS)JapanJP21H03598

Revision History  (Full details and data files)

  • Version 1.0: 2023-04-19
    Type: Initial release
  • Version 1.1: 2023-05-03
    Changes: Database references
  • Version 1.2: 2023-05-17
    Changes: Database references
