8EAM

SsoMCM hexamer bound to Mg/ADP-BeFx and DNA. Class 2. Merged particles from datasets with 3 different DNA entities


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.59 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Two Distinct Modes of DNA Binding by an MCM Helicase Enable DNA Translocation.

Meagher, M.Myasnikov, A.Enemark, E.J.

(2022) Int J Mol Sci 23

  • DOI: https://doi.org/10.3390/ijms232314678
  • Primary Citation of Related Structures:
    8EAF, 8EAG, 8EAH, 8EAI, 8EAJ, 8EAK, 8EAL, 8EAM

  • PubMed Abstract:

    A six-subunit ATPase ring forms the central hub of the replication forks in all domains of life. This ring performs a helicase function to separate the two complementary DNA strands to be replicated and drives the replication machinery along the DNA. Disruption of this helicase/ATPase ring is associated with genetic instability and diseases such as cancer. The helicase/ATPase rings of eukaryotes and archaea consist of six minichromosome maintenance (MCM) proteins. Prior structural studies have shown that MCM rings bind one encircled strand of DNA in a spiral staircase, suggesting that the ring pulls this strand of DNA through its central pore in a hand-over-hand mechanism where the subunit at the bottom of the staircase dissociates from DNA and re-binds DNA one step above the staircase. With high-resolution cryo-EM, we show that the MCM ring of the archaeal organism Saccharolobus solfataricus binds an encircled DNA strand in two different modes with different numbers of subunits engaged to DNA, illustrating a plausible mechanism for the alternating steps of DNA dissociation and re-association that occur during DNA translocation.


  • Organizational Affiliation

    Department of Structural Biology, St. Jude Children's Research Hospital, 262 Danny Thomas Place, Memphis, TN 38105, USA.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Minichromosome maintenance protein MCM
A, B, C, D, E
A, B, C, D, E, F
610Saccharolobus solfataricus P2Mutation(s): 0
Gene Names: MCMSSO0774
EC: 3.6.4.12
UniProt
Find proteins for Q9UXG1 (Saccharolobus solfataricus (strain ATCC 35092 / DSM 1617 / JCM 11322 / P2))
Explore Q9UXG1
Go to UniProtKB:  Q9UXG1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9UXG1
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
DNAG [auth X]12synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
08T (Subject of Investigation/LOI)
Query on 08T

Download Ideal Coordinates CCD File
K [auth B],
N [auth C],
Q [auth D],
T [auth E]
[[[(2R,3S,4R,5R)-5-(6-aminopurin-9-yl)-3,4-bis(oxidanyl)oxolan-2-yl]methoxy-oxidanyl-phosphoryl]oxy-oxidanyl-phosphoryl]oxy-tris(fluoranyl)beryllium
C10 H14 Be F3 N5 O10 P2
WOGYHYSOODLXII-KWIZKVQNSA-J
ZN
Query on ZN

Download Ideal Coordinates CCD File
H [auth A]
I [auth B]
L [auth C]
O [auth D]
R [auth E]
H [auth A],
I [auth B],
L [auth C],
O [auth D],
R [auth E],
U [auth F]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG (Subject of Investigation/LOI)
Query on MG

Download Ideal Coordinates CCD File
J [auth B],
M [auth C],
P [auth D],
S [auth E]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.59 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC3.31
MODEL REFINEMENTPHENIX1.20.1_4487

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM136313
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM098771

Revision History  (Full details and data files)

  • Version 1.0: 2022-12-14
    Type: Initial release
  • Version 1.1: 2022-12-21
    Changes: Database references
