8BJZ | pdb_00008bjz

crystal structure of antibody Fab with SiaLac-amidine-Lys

PDB DOI: https://doi.org/10.2210/pdb8BJZ/pdb

Classification: IMMUNE SYSTEM
Organism(s): Mus musculus
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2022-11-08 Released: 2023-09-27
Deposition Author(s): Moynie, L., Naismith, J.H.
Funding Organization(s): UK Research and Innovation (UKRI)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.89 Å
R-Value Free:
0.223 (Depositor), 0.220 (DCC)
R-Value Work:
0.186 (Depositor), 0.190 (DCC)
R-Value Observed:
0.188 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

crystal structure of antibody Fab with SiaLac-amidine-Lys

Moynie, L., Naismith, J.H., Sattentau, Q., Deimel, L., Khan, A., Davis, B., Baldwin, A., Buchanan, C.

To be published.

Macromolecule Content

Total Structure Weight: 99.09 kDa
Atom Count: 7,047
Modeled Residue Count: 857
Deposited Residue Count: 892
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
BAR-1 Fab heavy chain	A [auth H], C [auth A]	227	Mus musculus	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
BAR-1 Fab light chain	B [auth L], D [auth B]	219	Mus musculus	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
N-acetyl-alpha-neuraminic acid-(2-3)-beta-D-galactopyranose-(1-4)-beta-D-glucopyranose	E [auth C], F [auth D]	3		N/A	Interactions Focus chain E [auth C] Focus chain F [auth D] Interactions & Density Focus chain E [auth C] Focus chain F [auth D]
Glycosylation Resources
GlyTouCan: G91237TK GlyCosmos: G91237TK GlyGen: G91237TK

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SL9 (Subject of Investigation/LOI) Query on SL9 Download Ideal Coordinates CCD File SDF format, chain N [auth L] SDF format, chain U [auth B] MOL2 format, chain N [auth L] MOL2 format, chain U [auth B] mmCIF format, chain N [auth L] mmCIF format, chain U [auth B]	N [auth L], U [auth B]	(2~{S})-2-acetamido-6-(2-sulfanylethanimidoylamino)hexanamide C₁₀ H₂₀ N₄ O₂ S VZQPDVWZAWZPHB-QMMMGPOBSA-N		Interactions Focus chain N [auth L] Focus chain U [auth B] Interactions & Density Focus chain N [auth L] Focus chain U [auth B]
MES Query on MES Download Ideal Coordinates CCD File SDF format, chain H SDF format, chain P [auth A] MOL2 format, chain H MOL2 format, chain P [auth A] mmCIF format, chain H mmCIF format, chain P [auth A]	H, P [auth A]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C₆ H₁₃ N O₄ S SXGZJKUKBWWHRA-UHFFFAOYSA-N		Interactions Focus chain H Focus chain P [auth A] Interactions & Density Focus chain H Focus chain P [auth A]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain I [auth H] SDF format, chain J [auth H] SDF format, chain Q [auth A] SDF format, chain R [auth A] SDF format, chain K [auth L] MOL2 format, chain I [auth H] MOL2 format, chain J [auth H] MOL2 format, chain Q [auth A] MOL2 format, chain R [auth A] MOL2 format, chain K [auth L] mmCIF format, chain I [auth H] mmCIF format, chain J [auth H] mmCIF format, chain Q [auth A] mmCIF format, chain R [auth A] mmCIF format, chain K [auth L]	I [auth H], J [auth H], K [auth L], Q [auth A], R [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain I [auth H] Focus chain J [auth H] Focus chain K [auth L] Focus chain Q [auth A] Focus chain R [auth A] Interactions & Density Focus chain I [auth H] Focus chain J [auth H] Focus chain K [auth L] Focus chain Q [auth A] Focus chain R [auth A]
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain G [auth H] SDF format, chain L SDF format, chain M [auth L] SDF format, chain S [auth B] SDF format, chain T [auth B] SDF format, chain O [auth A] MOL2 format, chain G [auth H] MOL2 format, chain L MOL2 format, chain M [auth L] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] MOL2 format, chain O [auth A] mmCIF format, chain G [auth H] mmCIF format, chain L mmCIF format, chain M [auth L] mmCIF format, chain S [auth B] mmCIF format, chain T [auth B] mmCIF format, chain O [auth A]	G [auth H] L M [auth L] O [auth A] S [auth B] G [auth H], L, M [auth L], O [auth A], S [auth B], T [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain G [auth H] Focus chain L Focus chain M [auth L] Focus chain O [auth A] Focus chain S [auth B] Focus chain T [auth B] Interactions & Density Focus chain G [auth H] Focus chain L Focus chain M [auth L] Focus chain O [auth A] Focus chain S [auth B] Focus chain T [auth B]

Biologically Interesting Molecules (External Reference) 1 Unique

Entity ID: 3
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_002443 Query on PRD_002443	E [auth C], F [auth D]	SiaLac-amidine-Lys	Oligosaccharide /		Interactions Focus chain E [auth C] Focus chain F [auth D] Interactions & Density Focus chain E [auth C] Focus chain F [auth D]
