7YNN | pdb_00007ynn

ThT-bound alpha-synuclein fibrils conformation 2

PDB DOI: https://doi.org/10.2210/pdb7YNN/pdb
EM Map EMD-33966: EMDB EMDataResource

Classification: PROTEIN FIBRIL
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2022-07-31 Released: 2023-08-02
Deposition Author(s): Tao, Y.Q., Zhao, Q.Y., Liu, C., Li, D.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.90 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

wwPDB Validation 3D Report Full Report

Validation slider image for 7YNN

This is version 1.1 of the entry. See complete history.

Literature

ThT-bound alpha-synuclein fibrils conformation 2

Tao, Y.Q., Zhao, Q.Y., Liu, C., Li, D.

To be published.

Macromolecule Content

Total Structure Weight: 118.08 kDa
Atom Count: 3,528
Modeled Residue Count: 488
Deposited Residue Count: 1,120
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Alpha-synuclein	A B C D E [auth G] A, B, C, D, E [auth G], F [auth H], G [auth I], H [auth J]	140	Homo sapiens	Mutation(s): 0 Gene Names: SNCA, NACP, PARK1
UniProt & NIH Common Fund Data Resources
Find proteins for P37840 (Homo sapiens) Explore P37840 Go to UniProtKB: P37840
PHAROS: P37840 GTEx: ENSG00000145335
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P37840
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
TFX (Subject of Investigation/LOI) Query on TFX Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth B] SDF format, chain K [auth C] SDF format, chain L [auth D] SDF format, chain M [auth G] SDF format, chain N [auth H] SDF format, chain O [auth I] SDF format, chain P [auth J] MOL2 format, chain I [auth A] MOL2 format, chain J [auth B] MOL2 format, chain K [auth C] MOL2 format, chain L [auth D] MOL2 format, chain M [auth G] MOL2 format, chain N [auth H] MOL2 format, chain O [auth I] MOL2 format, chain P [auth J] mmCIF format, chain I [auth A] mmCIF format, chain J [auth B] mmCIF format, chain K [auth C] mmCIF format, chain L [auth D] mmCIF format, chain M [auth G] mmCIF format, chain N [auth H] mmCIF format, chain O [auth I] mmCIF format, chain P [auth J]	I [auth A] J [auth B] K [auth C] L [auth D] M [auth G] I [auth A], J [auth B], K [auth C], L [auth D], M [auth G], N [auth H], O [auth I], P [auth J]	2-[4-(dimethylamino)phenyl]-3,6-dimethyl-1,3-benzothiazol-3-ium C₁₇ H₁₉ N₂ S FXEKRIDRIFBJOR-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth B] Focus chain K [auth C] Focus chain L [auth D] Focus chain M [auth G] Focus chain N [auth H] Focus chain O [auth I] Focus chain P [auth J] Interactions & Density Focus chain I [auth A] Focus chain J [auth B] Focus chain K [auth C] Focus chain L [auth D] Focus chain M [auth G] Focus chain N [auth H] Focus chain O [auth I] Focus chain P [auth J]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.90 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-08-02

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2023-08-02
Type: Initial release
Version 1.1: 2024-07-03
Changes: Data collection
