7XRX

insulin-cleaving membrane protease-ICMP

• PDB DOI: https://doi.org/10.2210/pdb7XRX/pdb

• Classification: METAL BINDING PROTEIN
• Organism(s): Pseudomonas aeruginosa PAO1
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2022-05-12 Released: 2023-05-17
• Deposition Author(s): Wang, J.
• Funding Organization(s): National Natural Science Foundation of China (NSFC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.88 Å
• R-Value Free: 0.186
• R-Value Work: 0.146
• R-Value Observed: 0.148

Literature

Crystallization and X-ray diffraction analysis of native and selenomethionine-substituted ICMP from P. aeruginosa

Wang, J.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Biological Assembly 3

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 3 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 129.12 kDa
• Atom Count: 10,505
• Modelled Residue Count: 1,193
• Deposited Residue Count: 1,194
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Insulin-cleaving metalloproteinase outer membrane protein	A, B, C	398	Pseudomonas aeruginosa PAO1	Mutation(s): 0  Gene Names: icmP
UniProt
Find proteins for Q9HW32 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore Q9HW32  Go to UniProtKB:  Q9HW32

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CA (Subject of Investigation/LOI)	D [auth A], E [auth B], F [auth C]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.88 Å
• R-Value Free: 0.186
• R-Value Work: 0.146
• R-Value Observed: 0.148
• Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 87.927	α = 90
b = 78.141	β = 113.52
c = 99.916	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-05-17
Deposition Author(s): Wang, J.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History

• Version 1.0: 2023-05-17
  Type: Initial release
