7XMC

Cryo-EM structure of Cytochrome bo3 from Escherichia coli, apo structure with DMSO


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.09 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Identifying antibiotics based on structural differences in the conserved allostery from mitochondrial heme-copper oxidases.

Nishida, Y.Yanagisawa, S.Morita, R.Shigematsu, H.Shinzawa-Itoh, K.Yuki, H.Ogasawara, S.Shimuta, K.Iwamoto, T.Nakabayashi, C.Matsumura, W.Kato, H.Gopalasingam, C.Nagao, T.Qaqorh, T.Takahashi, Y.Yamazaki, S.Kamiya, K.Harada, R.Mizuno, N.Takahashi, H.Akeda, Y.Ohnishi, M.Ishii, Y.Kumasaka, T.Murata, T.Muramoto, K.Tosha, T.Shiro, Y.Honma, T.Shigeta, Y.Kubo, M.Takashima, S.Shintani, Y.

(2022) Nat Commun 13: 7591-7591

  • DOI: https://doi.org/10.1038/s41467-022-34771-y
  • Primary Citation of Related Structures:
    7XMA, 7XMB, 7XMC, 7XMD

  • PubMed Abstract:

    Antimicrobial resistance (AMR) is a global health problem. Despite the enormous efforts made in the last decade, threats from some species, including drug-resistant Neisseria gonorrhoeae, continue to rise and would become untreatable. The development of antibiotics with a different mechanism of action is seriously required. Here, we identified an allosteric inhibitory site buried inside eukaryotic mitochondrial heme-copper oxidases (HCOs), the essential respiratory enzymes for life. The steric conformation around the binding pocket of HCOs is highly conserved among bacteria and eukaryotes, yet the latter has an extra helix. This structural difference in the conserved allostery enabled us to rationally identify bacterial HCO-specific inhibitors: an antibiotic compound against ceftriaxone-resistant Neisseria gonorrhoeae. Molecular dynamics combined with resonance Raman spectroscopy and stopped-flow spectroscopy revealed an allosteric obstruction in the substrate accessing channel as a mechanism of inhibition. Our approach opens fresh avenues in modulating protein functions and broadens our options to overcome AMR.


  • Organizational Affiliation

    Department of Molecular Pharmacology, National Cerebral and Cardiovascular Center, Suita, Osaka, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Cytochrome bo(3) ubiquinol oxidase subunit 1663Escherichia coliMutation(s): 0
EC: 7.1.1.3
Membrane Entity: Yes
UniProt
Find proteins for P0ABI8 (Escherichia coli (strain K12))
Explore P0ABI8
Go to UniProtKB:  P0ABI8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ABI8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Ubiquinol oxidase subunit 2324Escherichia coliMutation(s): 0
Gene Names:
cyoAACU57_11830AM464_19145APX88_10780AWP93_14560BANRA_03634BEA19_24285BJI68_14080BJJ90_20095BK383_14750BMC79_002872BO068_001687BOB65_000403BON66_08870BON73_06180BON74_21890BON77_14335BON80_10695BON86_25900BON87_05825BON89_00395BON92_15695BON93_19065BON98_18690BSR05_07160BXT93_14110BZL69_16590C2121_000756C5N07_12950CA593_00980CDC27_01080CDL36_18475CDL37_08970CQP61_20675CR539_06390CT143_00345CXJ73_004380D0X26_07630D3822_17775D3Y67_14555D9E34_22950D9J03_07430DAH17_06675DAH34_12595DAH36_12985DD762_23785DKP82_19825DN627_04300DNQ45_18500DNX30_04955DTM16_23740DTM45_11185DU321_07410DXT70_02705E2119_01520E2122_05970E2131_02675E2135_01205E4K51_12275E5P26_04320E5P27_05630E5P28_11110E5P29_09785E5P31_06375E5P32_04100E5P34_04850E5P35_04720E5P36_01955E5P40_03855E5S36_14935E5S46_14035E5S51_13330E5S58_14090E5S61_17450EC3234A_4c01010EI021_16450EIA08_09775EIZ93_01035EL79_3413EL80_3367ELT17_06040ELT20_08135ELT41_07160ELT49_07745ELT51_19775ELU85_09175ELV10_08020ELV16_21785ELX48_13290ELX76_14920ELX85_08605EVY14_00280ExPECSC038_03272EYV17_02895EYV18_09930EYY21_23390F2N31_13445F3N40_15010F9S83_01735F9V24_00335FA849_16035FA868_02450FE587_05330FEJ01_04230FEL34_02865FGG80_03370FGY90_08715FHD44_10295FJQ51_12155FQF29_11475FTV93_12140FV293_05915FWK02_10070G3813_001713G4A38_05615G5603_08425GIB53_01940GKF86_04705GKF89_04260GLW94_08520GQM13_16545GQW68_14795GQW80_03945GRW05_22945GRW57_14390GRW81_04315GSY44_02240GTP88_03650GUB08_11340H0O53_01600HIN64_001359HJQ60_002319HJS37_002124HJU54_001612HL601_03105HLZ50_08430HMJ82_07910HMU48_15410HMV41_13070HMV95_11775HNC36_06575HNC59_10400HNC66_06810HNC99_09295HND12_08495HVW04_08795HVX16_19275HX136_19320IA00_004007IH772_12955IT029_003268J0541_001708JNP96_06590NCTC10082_01037NCTC10764_05312NCTC10974_04302NCTC11112_03815NCTC12950_04133NCTC13148_06650NCTC8008_03342NCTC8450_01418NCTC8500_04220NCTC8621_03944NCTC9037_03917NCTC9044_03552NCTC9117_04753PGD_02879SAMEA3472067_03229SAMEA3751407_02102WP2S18E08_34950

Membrane Entity: Yes
UniProt
Find proteins for P0ABJ1 (Escherichia coli (strain K12))
Explore P0ABJ1
Go to UniProtKB:  P0ABJ1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ABJ1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Cytochrome bo(3) ubiquinol oxidase subunit 3204Escherichia coliMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P0ABJ3 (Escherichia coli (strain K12))
Explore P0ABJ3
Go to UniProtKB:  P0ABJ3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ABJ3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Cytochrome bo(3) ubiquinol oxidase subunit 4109Escherichia coliMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P0ABJ6 (Escherichia coli (strain K12))
Explore P0ABJ6
Go to UniProtKB:  P0ABJ6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ABJ6
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
HEO
Query on HEO

Download Ideal Coordinates CCD File
E [auth A]HEME O
C49 H58 Fe N4 O5
FRKORVCRVCLRBA-BZKSIRDQSA-L
PEE
Query on PEE

Download Ideal Coordinates CCD File
H [auth A],
J [auth C]
1,2-dioleoyl-sn-glycero-3-phosphoethanolamine
C41 H78 N O8 P
MWRBNPKJOOWZPW-NYVOMTAGSA-N
HEM
Query on HEM

Download Ideal Coordinates CCD File
F [auth A]PROTOPORPHYRIN IX CONTAINING FE
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
CU
Query on CU

Download Ideal Coordinates CCD File
G [auth A]COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
UNX
Query on UNX

Download Ideal Coordinates CCD File
I [auth B]UNKNOWN ATOM OR ION
X
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.09 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONPHENIX
MODEL REFINEMENTPHENIX

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Science and TechnologyJapanJPMJCR14M2
Japan Agency for Medical Research and Development (AMED)JapanJP19im0210617

Revision History  (Full details and data files)

  • Version 1.0: 2022-12-21
    Type: Initial release
