7WR9 | pdb_00007wr9

Local CryoEM structure of the SARS-CoV S2P in complex with BD55-3152 Fab

• PDB DOI: https://doi.org/10.2210/pdb7WR9/pdb
• EM Map EMD-32719: EMDB EMDataResource

• Classification: VIRAL PROTEIN
• Organism(s): Homo sapiens, Severe acute respiratory syndrome coronavirus
• Expression System: Homo sapiens
• Mutation(s): No


• Deposited: 2022-01-26 Released: 2023-02-01
• Deposition Author(s): Du, S., Xiao, J.Y.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.24 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

Local CryoEM structure of the SARS-CoV S2P in complex with BD55-3152 Fab

Du, S., Xiao, J.Y.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1 Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 3-mer - A2B1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 74.13 kDa
• Atom Count: 3,266
• Modeled Residue Count: 411
• Deposited Residue Count: 673
• Unique protein chains: 3

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
BD55-3152H	A	260	Homo sapiens	Mutation(s): 0

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
BD55-3152L	B	233	Homo sapiens	Mutation(s): 0

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike protein S1	C [auth F]	180	Severe acute respiratory syndrome coronavirus	Mutation(s): 0  Gene Names: S, 2
UniProt
Find proteins for P59594 (Severe acute respiratory syndrome coronavirus) Explore P59594  Go to UniProtKB:  P59594
Glycosylation
Glycosylation Sites: 2		Go to GlyGen: P59594-1

Oligosaccharides

Help

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[alpha-L-fucopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranose	D [auth C]	4		N-Glycosylation
Glycosylation Resources
GlyTouCan: G32152BH GlyCosmos: G32152BH GlyGen: G32152BH

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NAG (Subject of Investigation/LOI)	E [auth F]	2-acetamido-2-deoxy-beta-D-glucopyranose C8 H15 N O6 OVRNDRQMDRJTHS-FMDGEEDCSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.24 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2023-02-01
Deposition Author(s): Du, S., Xiao, J.Y.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2023-02-01
  Type: Initial release

• Version 1.1: 2024-10-23
  Changes: Data collection, Structure summary
• Version 1.2: 2025-07-02
  Changes: Data collection
