7VEO

Crystal structure of juvenile hormone acid methyltransferase silkworm JHAMT isoform3 complex with S-Adenosyl-L-homocysteine


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.53 Å
  • R-Value Free: 0.241
  • R-Value Work: 0.192

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Structural characterization and functional analysis of juvenile hormone acid methyltransferase JHAMT3 from the silkworm, Bombyx mori.

Zhang, L.Xu, H.Zhang, Y.Zhang, H.Wang, Z.Guo, P.Zhao, P.

(2022) Insect Biochem Mol Biol 151: 103863-103863

  • DOI: https://doi.org/10.1016/j.ibmb.2022.103863
  • Primary Citation of Related Structures:
    7V2S, 7VEO

  • PubMed Abstract:

    Juvenile hormone acid methyltransferase (JHAMT) is a rate-limiting enzyme of juvenile hormone (JH) biosynthesis in insects. It transfers the methyl group of S-adenosyl methionine to either the carboxyl group of JH acids or farnesoic acid to produce JH. Six JHAMT paralogues have been identified in the silkworm (Bombyx mori); among them, JHAMT1 and JHAMT2 display a methyltransferase activity. Here, the three-dimensional crystal structure of inactive JHAMT3 and the binary complex of JHAMT3 with its cofactor S-adenosyl-l-homocysteine were determined through X-ray crystallization. Comparative structural analysis revealed that JHAMT3 adopted a similar structural pattern to that of functional JHAMT2, which comprised one core Rossmann fold domain and one substrate-binding domain. Similar to JHAMT2, JHAMT3 underwent a conformational change at the Rossmann fold domain because of cofactor binding, which promoted ligand accommodation. However, it exhibited a relatively rigid substrate-binding pocket compared with that of JHAMT2. JHAMT3 was also highly expressed in the silk gland of fourth- and fifth-instar B. mori larvae. The results of expression profiling combined with activity analysis suggested that JHAMT3 might function as a binding protein of JH acids for the regulation of JH acid titers. These findings provide a structural basis for enhancing the understanding of the physiological function of JHAMT3 and a rational framework for the development of potent and specific inhibitors of JHAMT family members.


  • Organizational Affiliation

    State Key Laboratory of Silkworm Genome Biology, Southwest University, Chongqing, 400715, China; Biological Science Research Center, Southwest University, Chongqing, 400716, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Methyltranfer_dom domain-containing protein
A, B
287Bombyx moriMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SAH (Subject of Investigation/LOI)
Query on SAH

Download Ideal Coordinates CCD File
C [auth B]S-ADENOSYL-L-HOMOCYSTEINE
C14 H20 N6 O5 S
ZJUKTBDSGOFHSH-WFMPWKQPSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.53 Å
  • R-Value Free: 0.241
  • R-Value Work: 0.192
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 149.15α = 90
b = 69.17β = 99.98
c = 57.82γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
xia2data reduction
Aimlessdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China31970468

Revision History  (Full details and data files)

  • Version 1.0: 2022-09-28
    Type: Initial release
  • Version 1.1: 2023-11-15
    Changes: Data collection, Database references
  • Version 1.2: 2023-11-29
    Changes: Refinement description
