7UF7 | pdb_00007uf7

Crystal structure of liganded Hb with the 5-HMF analog, MMA503

PDB DOI: https://doi.org/10.2210/pdb7UF7/pdb

Classification: OXYGEN TRANSPORT
Organism(s): Homo sapiens
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2022-03-22 Released: 2022-03-30
Deposition Author(s): Donkor, A.K., Musayev, F.N., Safo, M.K.
Funding Organization(s): National Institutes of Health/National Heart, Lung, and Blood Institute (NIH/NHLBI), National Institutes of Health/Eunice Kennedy Shriver National Institute of Child Health & Human Development (NIH/NICHD)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.223 (Depositor), 0.222 (DCC)
R-Value Work:
0.157 (Depositor), 0.158 (DCC)
R-Value Observed:
0.161 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Improving the antisickling activity of furaldehyde

El-Araby, M.E., Omar, A.M., Ghatge, M.S., Musayev, F.N., Donkor, A.K., Paredes, S.D., Abdulmalik, O., Safo, M.K.

To be published.

Macromolecule Content

Total Structure Weight: 65.48 kDa
Atom Count: 5,370
Modeled Residue Count: 574
Deposited Residue Count: 578
Unique protein chains: 2

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hemoglobin subunit alpha	A, C	142	Homo sapiens	Mutation(s): 0 Gene Names: HBA1, HBA2
UniProt & NIH Common Fund Data Resources
Find proteins for P69905 (Homo sapiens) Explore P69905 Go to UniProtKB: P69905
PHAROS: P69905 GTEx: ENSG00000188536 ENSG00000206172
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P69905
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Hemoglobin subunit beta	B, D	147	Homo sapiens	Mutation(s): 0 Gene Names: HBB
UniProt & NIH Common Fund Data Resources
Find proteins for P68871 (Homo sapiens) Explore P68871 Go to UniProtKB: P68871
PHAROS: P68871 GTEx: ENSG00000244734
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P68871
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
HEM (Subject of Investigation/LOI) Query on HEM Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain H [auth B] SDF format, chain J [auth C] SDF format, chain M [auth D] MOL2 format, chain E [auth A] MOL2 format, chain H [auth B] MOL2 format, chain J [auth C] MOL2 format, chain M [auth D] mmCIF format, chain E [auth A] mmCIF format, chain H [auth B] mmCIF format, chain J [auth C] mmCIF format, chain M [auth D]	E [auth A], H [auth B], J [auth C], M [auth D]	PROTOPORPHYRIN IX CONTAINING FE C₃₄ H₃₂ Fe N₄ O₄ KABFMIBPWCXCRK-RGGAHWMASA-L		Interactions Focus chain E [auth A] Focus chain H [auth B] Focus chain J [auth C] Focus chain M [auth D] Interactions & Density Focus chain E [auth A] Focus chain H [auth B] Focus chain J [auth C] Focus chain M [auth D]
N2Q (Subject of Investigation/LOI) Query on N2Q Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain L [auth C] MOL2 format, chain G [auth A] MOL2 format, chain L [auth C] mmCIF format, chain G [auth A] mmCIF format, chain L [auth C]	G [auth A], L [auth C]	(5P)-5-(5-methylfuran-2-yl)-1H-pyrazole C₈ H₈ N₂ O ZIJASYNQNLPMPY-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain L [auth C] Interactions & Density Focus chain G [auth A] Focus chain L [auth C]
CMO (Subject of Investigation/LOI) Query on CMO Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain I [auth B] SDF format, chain K [auth C] SDF format, chain N [auth D] MOL2 format, chain F [auth A] MOL2 format, chain I [auth B] MOL2 format, chain K [auth C] MOL2 format, chain N [auth D] mmCIF format, chain F [auth A] mmCIF format, chain I [auth B] mmCIF format, chain K [auth C] mmCIF format, chain N [auth D]	F [auth A], I [auth B], K [auth C], N [auth D]	CARBON MONOXIDE C O UGFAIRIUMAVXCW-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain I [auth B] Focus chain K [auth C] Focus chain N [auth D] Interactions & Density Focus chain F [auth A] Focus chain I [auth B] Focus chain K [auth C] Focus chain N [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.223 (Depositor), 0.222 (DCC)
R-Value Work: 0.157 (Depositor), 0.158 (DCC)
R-Value Observed: 0.161 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 62.614	α = 90
b = 83.12	β = 90
c = 105.122	γ = 90

Software Package:

Software Name	Purpose
Aimless	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
CrysalisPro	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-03-30

Deposition Author(s):

Donkor, A.K.

Musayev, F.N.

Safo, M.K.

Funding Organization	Location	Grant Number
National Institutes of Health/National Heart, Lung, and Blood Institute (NIH/NHLBI)	United States	R61HL156158
National Institutes of Health/Eunice Kennedy Shriver National Institute of Child Health & Human Development (NIH/NICHD)	United States	S10OD021756
