Crystal structure of a dehydrating condensation domain, AmbE-CmodAA, involved in nonribosomal peptide synthesis

Experimental Data Snapshot

  • Resolution: 2.14 Å
  • R-Value Free: 0.232
  • R-Value Work: 0.190
  • R-Value Observed: 0.191

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Structure and Function of a Dehydrating Condensation Domain in Nonribosomal Peptide Biosynthesis.

Patteson, J.B.Fortinez, C.M.Putz, A.T.Rodriguez-Rivas, J.Bryant 3rd, L.H.Adhikari, K.Weigt, M.Schmeing, T.M.Li, B.

(2022) J Am Chem Soc 144: 14057-14070

  • DOI: https://doi.org/10.1021/jacs.1c13404
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Dehydroamino acids are important structural motifs and biosynthetic intermediates for natural products. Many bioactive natural products of nonribosomal origin contain dehydroamino acids; however, the biosynthesis of dehydroamino acids in most nonribosomal peptides is not well understood. Here, we provide biochemical and bioinformatic evidence in support of the role of a unique class of condensation domains in dehydration (C modAA ). We also obtain the crystal structure of a C modAA domain, which is part of the nonribosomal peptide synthetase AmbE in the biosynthesis of the antibiotic methoxyvinylglycine. Biochemical analysis reveals that AmbE-C modAA modifies a peptide substrate that is attached to the donor carrier protein. Mutational studies of AmbE-C modAA identify several key residues for activity, including four residues that are mostly conserved in the C modAA subfamily. Alanine mutation of these conserved residues either significantly increases or decreases AmbE activity. AmbE exhibits a dimeric conformation, which is uncommon and could enable transfer of an intermediate between different protomers. Our discovery highlights a central dehydrating function for C modAA domains that unifies dehydroamino acid biosynthesis in diverse nonribosomal peptide pathways. Our work also begins to shed light on the mechanism of C modAA domains. Understanding C modAA domain function may facilitate identification of new natural products that contain dehydroamino acids and enable engineering of dehydroamino acids into nonribosomal peptides.

  • Organizational Affiliation

    Department of Chemistry, The University of North Carolina at Chapel Hill, Chapel Hill, North Carolina 27599, United States.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
A, B
438Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: ambEPA2302
Find proteins for Q9I1H3 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9I1H3
Go to UniProtKB:  Q9I1H3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9I1H3
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on IOD

Download Ideal Coordinates CCD File
C [auth A],
D [auth A],
E [auth A],
L [auth B],
M [auth B]
Query on NA

Download Ideal Coordinates CCD File
F [auth A]
G [auth A]
H [auth A]
I [auth A]
J [auth A]
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
N [auth B],
O [auth B],
P [auth B],
Q [auth B],
R [auth B],
S [auth B]
Experimental Data & Validation

Experimental Data

  • Resolution: 2.14 Å
  • R-Value Free: 0.232
  • R-Value Work: 0.190
  • R-Value Observed: 0.191
  • Space Group: I 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 89.94α = 90
b = 106.87β = 96.252
c = 108.909γ = 90
Software Package:
Software NamePurpose
MOSFLMdata reduction
Aimlessdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Canadian Institutes of Health Research (CIHR)CanadaFDN-148472

Revision History  (Full details and data files)

  • Version 1.0: 2022-07-13
    Type: Initial release
  • Version 1.1: 2022-08-10
    Changes: Database references
  • Version 1.2: 2022-08-24
    Changes: Database references
  • Version 1.3: 2023-10-18
    Changes: Data collection, Refinement description
