7Q17

Beta-lactoglobulin mutant FAW (I56F/L39A/M107W), unliganded form

PDB DOI: https://doi.org/10.2210/pdb7Q17/pdb

Classification: TRANSPORT PROTEIN
Organism(s): Bos taurus
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2021-10-18 Released: 2022-05-11
Deposition Author(s): Loch, J.I., Barciszewski, J., Lewinski, K.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.226
R-Value Work: 0.183

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

New ligand-binding sites identified in the crystal structures of [beta]-lactoglobulin complexes with desipramine

Loch, J.I., Barciszewski, J., Sliwiak, J., Bonarek, P., Wrobel, P., Pokrywka, K., Shabalin, I.G., Minor, W., Jaskolski, M., Lewinski, K.

(2022) IUCrJ 9: 386-398

DOI: https://doi.org/10.1107/S2052252522004183

Macromolecule Content

Total Structure Weight: 18.34 kDa
Atom Count: 1,353
Modelled Residue Count: 158
Deposited Residue Count: 162
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-lactoglobulin	A [auth AAA]	162	Bos taurus	Mutation(s): 5 Gene Names: LGB
UniProt
Find proteins for P02754 (Bos taurus) Explore P02754 Go to UniProtKB: P02754
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P02754
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain B [auth AAA] MOL2 format, chain B [auth AAA]	B [auth AAA]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain B [auth AAA] Interactions & Density Focus chain B [auth AAA]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.226
R-Value Work: 0.183
Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.083	α = 90
b = 53.083	β = 90
c = 111.469	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
XDS	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2022-05-11

Deposition Author(s):

Barciszewski, J.

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2022-05-11
Type: Initial release
Version 1.1: 2024-01-31
Changes: Data collection, Derived calculations, Refinement description
