7PXG | pdb_00007pxg

Verruculogen-bound Drosophila Slo channel

PDB DOI: https://doi.org/10.2210/pdb7PXG/pdb
EM Map EMD-13702: EMDB EMDataResource

Classification: TRANSPORT PROTEIN
Organism(s): Drosophila melanogaster
Expression System: Trichoplusia ni
Mutation(s): No
Membrane Protein: Yes OPM PDBTM MemProtMD

Deposited: 2021-10-08 Released: 2021-12-15
Deposition Author(s): Raisch, T., Brockmann, A., Ebbinghaus-Kintscher, U., Freigang, J., Gutbrod, O., Kubicek, J., Maertens, B., Hofnagel, O., Raunser, S.
Funding Organization(s): Max Planck Society

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.73 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Small molecule modulation of the Drosophila Slo channel elucidated by cryo-EM.

Raisch, T., Brockmann, A., Ebbinghaus-Kintscher, U., Freigang, J., Gutbrod, O., Kubicek, J., Maertens, B., Hofnagel, O., Raunser, S.

(2021) Nat Commun 12: 7164-7164

PubMed: 34887422 Search on PubMed Search on PubMed Central
DOI: https://doi.org/10.1038/s41467-021-27435-w
Primary Citation Related Structures:
7PXE, 7PXF, 7PXG, 7PXH

PubMed Abstract:
Slowpoke (Slo) potassium channels display extraordinarily high conductance, are synergistically activated by a positive transmembrane potential and high intracellular Ca ²⁺ concentrations and are important targets for insecticides and antiparasitic drugs. However, it is unknown how these compounds modulate ion translocation and whether there are insect-specific binding pockets. Here, we report structures of Drosophila Slo in the Ca ²⁺-bound and Ca ²⁺-free form and in complex with the fungal neurotoxin verruculogen and the anthelmintic drug emodepside. Whereas the architecture and gating mechanism of Slo channels are conserved, potential insect-specific binding pockets exist. Verruculogen inhibits K ⁺ transport by blocking the Ca ²⁺-induced activation signal and precludes K ⁺ from entering the selectivity filter. Emodepside decreases the conductance by suboptimal K ⁺ coordination and uncouples ion gating from Ca ²⁺ and voltage sensing. Our results expand the mechanistic understanding of Slo regulation and lay the foundation for the rational design of regulators of Slo and other voltage-gated ion channels.

Organizational Affiliation

Department of Structural Biochemistry, Max Planck Institute of Molecular Physiology, 44227, Dortmund, Germany.

Macromolecule Content

Total Structure Weight: 533.95 kDa
Atom Count: 28,664
Modeled Residue Count: 3,540
Deposited Residue Count: 4,720
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Isoform J of Calcium-activated potassium channel slowpoke	A, B, C, D	1,180	Drosophila melanogaster	Mutation(s): 0 Gene Names: slo, CG10693 Membrane Entity: Yes
UniProt
Find proteins for Q03720 (Drosophila melanogaster) Explore Q03720 Go to UniProtKB: Q03720
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q03720
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
6PL Query on 6PL Download:Ideal Coordinates CCD File SDF format, chain AA [auth C] SDF format, chain HA [auth D] SDF format, chain I [auth A] SDF format, chain IA [auth D] SDF format, chain T [auth B] SDF format, chain V [auth C] SDF format, chain S [auth B] SDF format, chain BA [auth C] MOL2 format, chain AA [auth C] MOL2 format, chain HA [auth D] MOL2 format, chain I [auth A] MOL2 format, chain IA [auth D] MOL2 format, chain T [auth B] MOL2 format, chain V [auth C] MOL2 format, chain S [auth B] MOL2 format, chain BA [auth C] mmCIF format, chain AA [auth C] mmCIF format, chain HA [auth D] mmCIF format, chain I [auth A] mmCIF format, chain IA [auth D] mmCIF format, chain T [auth B] mmCIF format, chain V [auth C] mmCIF format, chain S [auth B] mmCIF format, chain BA [auth C]	AA [auth C] BA [auth C] HA [auth D] I [auth A] IA [auth D] AA [auth C], BA [auth C], HA [auth D], I [auth A], IA [auth D], S [auth B], T [auth B], V [auth C]	(4S,7R)-4-HYDROXY-N,N,N-TRIMETHYL-9-OXO-7-[(PALMITOYLOXY)METHYL]-3,5,8-TRIOXA-4-PHOSPHAHEXACOSAN-1-AMINIUM 4-OXIDE C₄₂ H₈₅ N O₈ P PZNPLUBHRSSFHT-RRHRGVEJSA-O		Interactions Focus chain AA [auth C] Focus chain BA [auth C] Focus chain HA [auth D] Focus chain I [auth A] Focus chain IA [auth D] Focus chain S [auth B] Focus chain T [auth B] Focus chain V [auth C] Interactions & Density Focus chain AA [auth C] Focus chain BA [auth C] Focus chain HA [auth D] Focus chain I [auth A] Focus chain IA [auth D] Focus chain S [auth B] Focus chain T [auth B] Focus chain V [auth C]
8H5 (Subject of Investigation/LOI) Query on 8H5 Download:Ideal Coordinates CCD File SDF format, chain DA [auth D] SDF format, chain E [auth A] SDF format, chain O [auth B] SDF format, chain W [auth C] MOL2 format, chain DA [auth D] MOL2 format, chain E [auth A] MOL2 format, chain O [auth B] MOL2 format, chain W [auth C] mmCIF format, chain DA [auth D] mmCIF format, chain E [auth A] mmCIF format, chain O [auth B] mmCIF format, chain W [auth C]	DA [auth D], E [auth A], O [auth B], W [auth C]	Verruculogen C₂₇ H₃₃ N₃ O₇ LRXYHMMJJCTUMY-GWXUGYLUSA-N		Interactions Focus chain DA [auth D] Focus chain E [auth A] Focus chain O [auth B] Focus chain W [auth C] Interactions & Density Focus chain DA [auth D] Focus chain E [auth A] Focus chain O [auth B] Focus chain W [auth C]
CLR Query on CLR Download:Ideal Coordinates CCD File SDF format, chain J [auth A] SDF format, chain U [auth B] SDF format, chain JA [auth D] SDF format, chain CA [auth C] MOL2 format, chain J [auth A] MOL2 format, chain U [auth B] MOL2 format, chain JA [auth D] MOL2 format, chain CA [auth C] mmCIF format, chain J [auth A] mmCIF format, chain U [auth B] mmCIF format, chain JA [auth D] mmCIF format, chain CA [auth C]	CA [auth C], J [auth A], JA [auth D], U [auth B]	CHOLESTEROL C₂₇ H₄₆ O HVYWMOMLDIMFJA-DPAQBDIFSA-N		Interactions Focus chain CA [auth C] Focus chain J [auth A] Focus chain JA [auth D] Focus chain U [auth B] Interactions & Density Focus chain CA [auth C] Focus chain J [auth A] Focus chain JA [auth D] Focus chain U [auth B]
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain EA [auth D] SDF format, chain P [auth B] SDF format, chain Q [auth B] SDF format, chain X [auth C] SDF format, chain Y [auth C] SDF format, chain G [auth A] SDF format, chain FA [auth D] SDF format, chain F [auth A] MOL2 format, chain EA [auth D] MOL2 format, chain P [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain X [auth C] MOL2 format, chain Y [auth C] MOL2 format, chain G [auth A] MOL2 format, chain FA [auth D] MOL2 format, chain F [auth A] mmCIF format, chain EA [auth D] mmCIF format, chain P [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain X [auth C] mmCIF format, chain Y [auth C] mmCIF format, chain G [auth A] mmCIF format, chain FA [auth D] mmCIF format, chain F [auth A]	EA [auth D] F [auth A] FA [auth D] G [auth A] P [auth B] EA [auth D], F [auth A], FA [auth D], G [auth A], P [auth B], Q [auth B], X [auth C], Y [auth C]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain EA [auth D] Focus chain F [auth A] Focus chain FA [auth D] Focus chain G [auth A] Focus chain P [auth B] Focus chain Q [auth B] Focus chain X [auth C] Focus chain Y [auth C] Interactions & Density Focus chain EA [auth D] Focus chain F [auth A] Focus chain FA [auth D] Focus chain G [auth A] Focus chain P [auth B] Focus chain Q [auth B] Focus chain X [auth C] Focus chain Y [auth C]
K Query on K Download:Ideal Coordinates CCD File SDF format, chain N [auth A] SDF format, chain M [auth A] SDF format, chain L [auth A] SDF format, chain K [auth A] MOL2 format, chain N [auth A] MOL2 format, chain M [auth A] MOL2 format, chain L [auth A] MOL2 format, chain K [auth A] mmCIF format, chain N [auth A] mmCIF format, chain M [auth A] mmCIF format, chain L [auth A] mmCIF format, chain K [auth A]	K [auth A], L [auth A], M [auth A], N [auth A]	POTASSIUM ION K NPYPAHLBTDXSSS-UHFFFAOYSA-N		Interactions Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Interactions & Density Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain R [auth B] SDF format, chain Z [auth C] SDF format, chain GA [auth D] MOL2 format, chain H [auth A] MOL2 format, chain R [auth B] MOL2 format, chain Z [auth C] MOL2 format, chain GA [auth D] mmCIF format, chain H [auth A] mmCIF format, chain R [auth B] mmCIF format, chain Z [auth C] mmCIF format, chain GA [auth D]	GA [auth D], H [auth A], R [auth B], Z [auth C]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain GA [auth D] Focus chain H [auth A] Focus chain R [auth B] Focus chain Z [auth C] Interactions & Density Focus chain GA [auth D] Focus chain H [auth A] Focus chain R [auth B] Focus chain Z [auth C]
