7PTI

STRUCTURAL EFFECTS INDUCED BY REMOVAL OF A DISULFIDE BRIDGE. THE X-RAY STRUCTURE OF THE C30A(SLASH)C51A MUTANT OF BASIC PANCREATIC TRYPSIN INHIBITOR AT 1.6 ANGSTROMS


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Observed: 0.170

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Structural effects induced by removal of a disulfide-bridge: the X-ray structure of the C30A/C51A mutant of basic pancreatic trypsin inhibitor at 1.6 A.

Eigenbrot, C.Randal, M.Kossiakoff, A.A.

(1990) Protein Eng 3: 591-598

  • DOI: https://doi.org/10.1093/protein/3.7.591
  • Primary Citation of Related Structures:
    7PTI

  • PubMed Abstract:

    The X-ray structure of a variant of basic pancreatic trypsin inhibitor (BPTI) has been analyzed to determine the structural accommodation resulting from removal of a disulfide cross-link in a protein. The disulfide removed, Cys30-Cys51, has been implicated in both the folding pathway of the protein and its overall thermal stability. In the variant studied, C30A/C51A, the disulfide cysteines were replaced by less bulky alanines. The atomic displacements observed for C30A/C51A indicate a set of concerted shifts of two segments of chains, which together significantly diminish a packing defect at the site of the removed cysteine sulfur atoms. The observed structural changes are distributed asymmetrically around the sites of mutation, indicating that the adjacent beta-sheet is more resistant to the perturbation than the alpha-helix on the opposite side of the disulfide bond. The thermal parameters of groups involved in the structural accommodation are not significantly altered. A comparison of the X-ray structures reported for native BPTI determined in three different crystal forms indicates that the magnitude of its conformational variability exceeds that of the structural changes caused by the disulfide removal. This emphasizes the necessity of using isomorphous crystal systems to determine the relatively small effects due to mutation.


  • Organizational Affiliation

    Department of Biomolecular Chemistry, Genentech Inc., South San Francisco, CA 94080.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
BOVINE PANCREATIC TRYPSIN INHIBITOR58Bos taurusMutation(s): 0
UniProt
Find proteins for P00974 (Bos taurus)
Explore P00974
Go to UniProtKB:  P00974
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00974
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PO4
Query on PO4

Download Ideal Coordinates CCD File
B [auth A]PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Observed: 0.170
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.36α = 90
b = 23.26β = 90
c = 28.88γ = 90
Software Package:
Software NamePurpose
PROLSQrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1991-04-15
    Type: Initial release
  • Version 1.1: 2008-03-25
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2024-06-05
    Changes: Data collection, Database references, Derived calculations, Other
  • Version 1.4: 2024-11-20
    Changes: Structure summary
