7PNN | pdb_00007pnn

mVenus released from fusion protein.

PDB DOI: https://doi.org/10.2210/pdb7PNN/pdb

Classification: FLUORESCENT PROTEIN
Organism(s): Aequorea victoria
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2021-09-07 Released: 2021-11-03
Deposition Author(s): Bloch, Y., Savvides, S.N.
Funding Organization(s): Research Foundation - Flanders (FWO)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.43 Å
R-Value Free:
0.169 (Depositor), 0.175 (DCC)
R-Value Work:
0.162 (Depositor)
R-Value Observed:
0.162 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7PNN

This is version 2.2 of the entry. See complete history.

Literature

mVenus released from fusion protein.

Bloch, Y., Savvides, S.N.

To be published.

Macromolecule Content

Total Structure Weight: 27.77 kDa
Atom Count: 2,138
Modeled Residue Count: 229
Deposited Residue Count: 243
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
mVenus	A	243	Aequorea victoria	Mutation(s): 11 Gene Names: yfp
UniProt
Find proteins for P42212 (Aequorea victoria) Explore P42212 Go to UniProtKB: P42212
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P42212
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CR2 Query on CR2	A	L-PEPTIDE LINKING	C₁₃ H₁₃ N₃ O₄		GLY, TYR, GLY

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.43 Å
R-Value Free: 0.169 (Depositor), 0.175 (DCC)
R-Value Work: 0.162 (Depositor)
R-Value Observed: 0.162 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 61.064	α = 90
b = 91.048	β = 90
c = 118.556	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2021-11-03

Deposition Author(s):

Funding Organization	Location	Grant Number
Research Foundation - Flanders (FWO)	Belgium	--

Revision History (Full details and data files)

Version 1.0: 2021-11-03
Type: Initial release
Version 2.0: 2023-11-15
Changes: Atomic model, Data collection
Version 2.1: 2024-01-31
Changes: Refinement description
Version 2.2: 2024-11-13
Changes: Structure summary
