7OUU

Crystal structure of human filamin C domains 14-15

PDB DOI: https://doi.org/10.2210/pdb7OUU/pdb

Classification: STRUCTURAL PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2021-06-13 Released: 2022-06-22
Deposition Author(s): Mlynek, G., Djinovic-Carugo, K.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.47 Å
R-Value Free: 0.228
R-Value Work: 0.188
R-Value Observed: 0.189

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Analysis and prediction of pathogenic missense variants in human filamin C

Mlynek, G., Djinovic-Carugo, K.

To be published.

Macromolecule Content

Total Structure Weight: 42.96 kDa
Atom Count: 3,379
Modelled Residue Count: 406
Deposited Residue Count: 410
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Isoform 2 of Filamin-C	A, B	205	Homo sapiens	Mutation(s): 0 Gene Names: FLNC, ABPL, FLN2
UniProt & NIH Common Fund Data Resources
Find proteins for Q14315 (Homo sapiens) Explore Q14315 Go to UniProtKB: Q14315
PHAROS: Q14315 GTEx: ENSG00000128591
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q14315
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.47 Å
R-Value Free: 0.228
R-Value Work: 0.188
R-Value Observed: 0.189
Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.04	α = 90
b = 58.82	β = 90
c = 178.31	γ = 90

Software Package:

Software Name	Purpose
ARP/wARP	model building
PHENIX	refinement
XDS	data reduction
XDS	data scaling
MoRDa	phasing
PDB-REDO	refinement
GDA	data collection
Coot	model building

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2022-06-22

Deposition Author(s):

Djinovic-Carugo, K.

Revision History (Full details and data files)

Version 1.0: 2022-06-22
Type: Initial release
