7OUN

Structure of human PD-L1 in complex with macrocyclic inhibitor

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.232
  • R-Value Observed: 0.233

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history.


Literature

Structural Characterization of a Macrocyclic Peptide Modulator of the PD-1/PD-L1 Immune Checkpoint Axis.

Zyla, E., Musielak, B., Holak, T.A., Dubin, G.

(2021) Molecules 26

  • DOI: 10.3390/molecules26164848
  • Primary Citation of Related Structures:
    7OUN

  • PubMed Abstract:

    • The clinical success of PD-1/PD-L1 immune checkpoint targeting antibodies in cancer is followed by efforts to develop small molecule inhibitors with better penetration into solid tumors and more favorable pharmacokinetics. Here we report the crystal structure of a macrocyclic peptide inhibitor (peptide 104) in complex with PD-L1 ...

    The clinical success of PD-1/PD-L1 immune checkpoint targeting antibodies in cancer is followed by efforts to develop small molecule inhibitors with better penetration into solid tumors and more favorable pharmacokinetics. Here we report the crystal structure of a macrocyclic peptide inhibitor (peptide 104) in complex with PD-L1. Our structure shows no indication of an unusual bifurcated binding mode demonstrated earlier for another peptide of the same family (peptide 101). The binding mode relies on extensive hydrophobic interactions at the center of the binding surface and an electrostatic patch at the side. An interesting sulfur/π interaction supports the macrocycle-receptor binding. Overall, our results allow a better understanding of forces guiding macrocycle affinity for PD-L1, providing a rationale for future structure-based inhibitor design and rational optimization.

    Organizational Affiliation:

    Malopolska Centre of Biotechnology, Jagiellonian University, Gronostajowa 7A, 30-387 Krakow, Poland.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Programmed cell death 1 ligand 1A129Homo sapiensMutation(s): 0
Gene Names: CD274, B7H1, PDCD1L1, PDCD1LG1, PDL1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NZQ7 (Homo sapiens)
Explore Q9NZQ7
Go to UniProtKB:  Q9NZQ7
PHAROS:  Q9NZQ7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NZQ7
Protein Feature View
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
macrocyclic peptideB14synthetic constructMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.232
  • R-Value Observed: 0.233
  • Space Group: P 2 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 86.47α = 90
b = 86.47β = 90
c = 86.47γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
SCALAdata scaling
PDB_EXTRACTdata extraction
iMOSFLMdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Polish National Science CentrePolandUMO-2017/25/B/NZ1/00827

Revision History  (Full details and data files)

  • Version 1.0: 2021-09-15
    Type: Initial release
