7OLW | pdb_00007olw

Structure of the N-terminal domain of BC2L-C lectin (1-131) in complex with a synthetic beta-N-fucoside ligand


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.32 Å
  • R-Value Free:
    0.129 (Depositor), 0.139 (DCC)
  • R-Value Work:
    0.103 (Depositor), 0.112 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7OLW

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Targeting a Multidrug-Resistant Pathogen: First Generation Antagonists of Burkholderia cenocepacia 's BC2L-C Lectin.

Bermeo, R.Lal, K.Ruggeri, D.Lanaro, D.Mazzotta, S.Vasile, F.Imberty, A.Belvisi, L.Varrot, A.Bernardi, A.

(2022) ACS Chem Biol 17: 2899-2910

  • DOI: https://doi.org/10.1021/acschembio.2c00532
  • Primary Citation Related Structures:
    7OLU, 7OLW

  • PubMed Abstract:

    Multidrug-resistant pathogens such as Burkholderia cenocepacia have become a hazard in the context of healthcare-associated infections, especially for patients admitted with cystic fibrosis or immuno-compromising conditions. Like other opportunistic Gram-negative bacteria, this pathogen establishes virulence and biofilms through lectin-mediated adhesion. In particular, the superlectin BC2L-C is believed to cross-link human epithelial cells to B. cenocepacia during pulmonary infections. We aimed to obtain glycomimetic antagonists able to inhibit the interaction between the N -terminal domain of BC2L-C (BC2L-C-Nt) and its target fucosylated human oligosaccharides. In a previous study, we identified by fragment virtual screening and validated a small set of molecular fragments that bind BC2L-C-Nt in the vicinity of the fucose binding site. Here, we report the rational design and synthesis of bifunctional C - or N -fucosides, generated by connecting these fragments to a fucoside core using a panel of rationally selected linkers. A modular route starting from two key fucoside intermediates was implemented for the synthesis, followed by evaluation of the new compounds as BC2L-C-Nt ligands with a range of techniques (surface plasmon resonance, isothermal titration calorimetry, saturation transfer difference NMR, differential scanning calorimetry, and X-ray crystallography). This study resulted in a hit molecule with an order of magnitude gain over the starting methyl fucoside and in two crystal structures of antagonist/lectin complexes.


  • Organizational Affiliation
    • CNRS, CERMAV, Univ. Grenoble Alpes, Grenoble 38000, France.

Macromolecule Content

  • Total Structure Weight: 14.36 kDa
  • Atom Count: 1,226
  • Modeled Residue Count: 134
  • Deposited Residue Count: 134
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
LectinA [auth AAA]134Burkholderia cenocepacia J2315Mutation(s): 0
Gene Names: BCAM0185
UniProt
Find proteins for B4EH86 (Burkholderia cenocepacia (strain ATCC BAA-245 / DSM 16553 / LMG 16656 / NCTC 13227 / J2315 / CF5610))
Explore B4EH86
Go to UniProtKB:  B4EH86
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB4EH86
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
VJW
(Subject of Investigation/LOI)

Query on VJW



Download:Ideal Coordinates CCD File
B [auth AAA]5-(3-aminophenyl)furan-2-carboxamido-(beta-L-fucopyranose)
C17 H20 N2 O6
QWRWVIPPQRQFMW-VUBKLASDSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.32 Å
  • R-Value Free:  0.129 (Depositor), 0.139 (DCC)
  • R-Value Work:  0.103 (Depositor), 0.112 (DCC)
Space Group: P 63
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.931α = 90
b = 42.931β = 90
c = 94.882γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
H2020 Marie Curie Actions of the European CommissionFrance765581

Revision History  (Full details and data files)

  • Version 1.0: 2022-06-01
    Type: Initial release
  • Version 1.1: 2022-11-30
    Changes: Database references, Derived calculations
  • Version 1.2: 2024-01-31
    Changes: Data collection, Refinement description
