7MU8

Structure of the minimally glycosylated human CEACAM1 N-terminal domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.202
  • R-Value Observed: 0.203

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Human CEACAM1 N-domain dimerization is independent from glycan modifications.

Belcher Dufrisne, M.Swope, N.Kieber, M.Yang, J.Y.Han, J.Li, J.Moremen, K.W.Prestegard, J.H.Columbus, L.

(2022) Structure 30: 658-670.e5

  • DOI: https://doi.org/10.1016/j.str.2022.02.003
  • Primary Citation of Related Structures:
    7MU8

  • PubMed Abstract:

    Carcinoembryonic cellular adhesion molecules (CEACAMs) serve diverse roles in cell signaling, proliferation, and survival and are made up of one or several immunoglobulin (Ig)-like ectodomains glycosylated in vivo. The physiological oligomeric state and how it contributes to protein function are central to understanding CEACAMs. Two putative dimer conformations involving different CEACAM1 N-terminal Ig-like domain (CCM1) protein faces (ABED and GFCC'C″) were identified from crystal structures. GFCC'C″ was identified as the dominant CCM1 solution dimer, but ambiguity regarding the effect of glycosylation on dimer formation calls its physiological relevance into question. We present the first crystal structure of minimally glycosylated CCM1 in the GFCC'C″ dimer conformation and characterization in solution by continuous-wave and double electron-electron resonance electron paramagnetic resonance spectroscopy. Our results suggest the GFCC'C″ dimer is dominant in solution with different levels of glycosylation, and structural conservation and co-evolved residues support that the GFCC'C″ dimer is conserved across CEACAMs.


  • Organizational Affiliation

    Department of Chemistry, University of Virginia, Charlottesville, VA 22904, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Carcinoembryonic antigen-related cell adhesion molecule 1
A, B
107Homo sapiensMutation(s): 0
Gene Names: CEACAM1BGPBGP1
UniProt & NIH Common Fund Data Resources
Find proteins for P13688 (Homo sapiens)
Explore P13688
Go to UniProtKB:  P13688
PHAROS:  P13688
GTEx:  ENSG00000079385
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP13688
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NAG (Subject of Investigation/LOI)
Query on NAG

Download Ideal Coordinates CCD File
C [auth A],
K [auth B],
L [auth B]
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
J [auth A]SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
D [auth A]
E [auth A]
F [auth A]
G [auth A]
H [auth A]
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
M [auth B],
N [auth B],
O [auth B],
P [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.202
  • R-Value Observed: 0.203
  • Space Group: H 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 93.455α = 90
b = 93.455β = 90
c = 134.665γ = 120
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling
PHASERphasing
Cootmodel building
PHENIXrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01 GM087828
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR35 GM131829
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesP41 GM103390
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesF32 GM136076

Revision History  (Full details and data files)

  • Version 1.0: 2022-02-09
    Type: Initial release
  • Version 1.1: 2022-08-24
    Changes: Database references
  • Version 1.2: 2023-10-18
    Changes: Data collection, Refinement description
