7MJD

Crystal Structure Analysis of ALDH1B1

PDB DOI: https://doi.org/10.2210/pdb7MJD/pdb

Classification: OXIDOREDUCTASE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2021-04-20 Released: 2022-06-08
Deposition Author(s): Fernandez, D., Chen, J.K.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.12 Å
R-Value Free: 0.219
R-Value Work: 0.180
R-Value Observed: 0.182

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Inhibitors targeted to aldehyde dehydrogenase

Fernandez, D.

(2022) Nat Chem Biol

Macromolecule Content

Total Structure Weight: 116.84 kDa
Atom Count: 8,130
Modelled Residue Count: 986
Deposited Residue Count: 996
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Aldehyde dehydrogenase X, mitochondrial	A, B	498	Homo sapiens	Mutation(s): 2 Gene Names: ALDH1B1, ALDH5, ALDHX EC: 1.2.1.3
UniProt & NIH Common Fund Data Resources
Find proteins for P30837 (Homo sapiens) Explore P30837 Go to UniProtKB: P30837
PHAROS: P30837 GTEx: ENSG00000137124
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P30837
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAD Query on NAD Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain R [auth B] MOL2 format, chain D [auth A] MOL2 format, chain R [auth B] mmCIF format, chain D [auth A] mmCIF format, chain R [auth B]	D [auth A], R [auth B]	NICOTINAMIDE-ADENINE-DINUCLEOTIDE C₂₁ H₂₇ N₇ O₁₄ P₂ BAWFJGJZGIEFAR-NNYOXOHSSA-N		Interactions Focus chain D [auth A] Focus chain R [auth B] Interactions & Density Focus chain D [auth A] Focus chain R [auth B]
ZGG (Subject of Investigation/LOI) Query on ZGG Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain S [auth B] MOL2 format, chain E [auth A] MOL2 format, chain S [auth B] mmCIF format, chain E [auth A] mmCIF format, chain S [auth B]	E [auth A], S [auth B]	8-(2-methoxyphenyl)-10-(4-phenylphenyl)-1$l^{4},8-diazabicyclo[5.3.0]deca-1(7),9-diene C₂₇ H₂₇ N₂ O ZXQNQLPFZBEUMQ-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain S [auth B] Interactions & Density Focus chain E [auth A] Focus chain S [auth B]
1PE Query on 1PE Download Ideal Coordinates CCD File SDF format, chain AA [auth B] SDF format, chain BA [auth B] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] SDF format, chain V [auth B] SDF format, chain W [auth B] SDF format, chain X [auth B] SDF format, chain Y [auth B] SDF format, chain Z [auth B] MOL2 format, chain AA [auth B] MOL2 format, chain BA [auth B] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] MOL2 format, chain V [auth B] MOL2 format, chain W [auth B] MOL2 format, chain X [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain Z [auth B] mmCIF format, chain AA [auth B] mmCIF format, chain BA [auth B] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain P [auth A] mmCIF format, chain V [auth B] mmCIF format, chain W [auth B] mmCIF format, chain X [auth B] mmCIF format, chain Y [auth B] mmCIF format, chain Z [auth B]	AA [auth B] BA [auth B] F [auth A] G [auth A] H [auth A] AA [auth B], BA [auth B], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A], V [auth B], W [auth B], X [auth B], Y [auth B], Z [auth B]	PENTAETHYLENE GLYCOL C₁₀ H₂₂ O₆ JLFNLZLINWHATN-UHFFFAOYSA-N		Interactions Focus chain AA [auth B] Focus chain BA [auth B] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth B] Focus chain BA [auth B] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain T [auth B] SDF format, chain U [auth B] MOL2 format, chain T [auth B] MOL2 format, chain U [auth B] mmCIF format, chain T [auth B] mmCIF format, chain U [auth B]	T [auth B], U [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain T [auth B] Focus chain U [auth B] Interactions & Density Focus chain T [auth B] Focus chain U [auth B]
NA Query on NA Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain Q [auth B] MOL2 format, chain C [auth A] MOL2 format, chain Q [auth B] mmCIF format, chain C [auth A] mmCIF format, chain Q [auth B]	C [auth A], Q [auth B]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain Q [auth B] Interactions & Density Focus chain C [auth A] Focus chain Q [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.12 Å
R-Value Free: 0.219
R-Value Work: 0.180
R-Value Observed: 0.182
Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 102.04	α = 90
b = 102.04	β = 90
c = 186.037	γ = 120

Software Package:

Software Name	Purpose
XDS	data reduction
SCALA	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2022-06-08

Deposition Author(s):

Fernandez, D.

Chen, J.K.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	GM127030
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	GM113100
