7L69

Crystal structure of human polymerase eta complexed with syn N7-benzylguanine

• PDB DOI: https://doi.org/10.2210/pdb7L69/pdb
• NAKB: 7L69

• Classification: REPLICATION
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2020-12-23 Released: 2022-01-05
• Deposition Author(s): Jung, H., Lee, S.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.91 Å
• R-Value Free: 0.224
• R-Value Work: 0.187
• R-Value Observed: 0.189

Literature

Crystal structure of human polymerase eta complexed with syn N7-benzylguanine

Jung, H., Lee, S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 54.52 kDa
• Atom Count: 3,956
• Modelled Residue Count: 446
• Deposited Residue Count: 452
• Unique protein chains: 1
• Unique nucleic acid chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA polymerase eta	A	432	Homo sapiens	Mutation(s): 0  Gene Names: POLH, RAD30, RAD30A, XPV EC: 2.7.7.7
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y253 (Homo sapiens) Explore Q9Y253  Go to UniProtKB:  Q9Y253
PHAROS:  Q9Y253 GTEx:  ENSG00000170734

Entity ID: 2
Molecule	Chains	Length	Organism	Image
DNA (5'-D(*CP*AP*TP*(7BG)P*CP*TP*CP*AP*CP*AP*CP*T)-3')	B [auth T]	12	Homo sapiens

Entity ID: 3
Molecule	Chains	Length	Organism	Image
DNA (5'-D(*AP*GP*TP*GP*TP*GP*AP*G)-3')	C [auth P]	8	Homo sapiens

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.91 Å
• R-Value Free: 0.224
• R-Value Work: 0.187
• R-Value Observed: 0.189
• Space Group: P 6₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 98.994	α = 90
b = 98.994	β = 90
c = 81.886	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2022-01-05
Deposition Author(s): Jung, H., Lee, S.

Revision History

• Version 1.0: 2022-01-05
  Type: Initial release

• Version 1.1: 2023-10-18
  Changes: Data collection, Refinement description
