7KPG

Blocking Fab 25 anti-SIRP-alpha antibody in complex with SIRP-alpha Variant 1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.27 Å
  • R-Value Free: 0.282
  • R-Value Work: 0.234
  • R-Value Observed: 0.237

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Targeting the myeloid checkpoint receptor SIRP alpha potentiates innate and adaptive immune responses to promote anti-tumor activity.

Kuo, T.C.Chen, A.Harrabi, O.Sockolosky, J.T.Zhang, A.Sangalang, E.Doyle, L.V.Kauder, S.E.Fontaine, D.Bollini, S.Han, B.Fu, Y.X.Sim, J.Pons, J.Wan, H.I.

(2020) J Hematol Oncol 13: 160-160

  • DOI: https://doi.org/10.1186/s13045-020-00989-w
  • Primary Citation of Related Structures:
    7KPG

  • PubMed Abstract:

    Signal regulatory protein α (SIRPα) is a myeloid-lineage inhibitory receptor that restricts innate immunity through engagement of its cell surface ligand CD47. Blockade of the CD47-SIRPα interaction synergizes with tumor-specific antibodies and T-cell checkpoint inhibitors by promoting myeloid-mediated antitumor functions leading to the induction of adaptive immunity. Inhibition of the CD47-SIRPα interaction has focused predominantly on targeting CD47, which is expressed ubiquitously and contributes to the accelerated blood clearance of anti-CD47 therapeutics. Targeting SIRPα, which is myeloid-restricted, may provide a differential pharmacokinetic, safety, and efficacy profile; however, SIRPα polymorphisms and lack of pan-allelic and species cross-reactive agents have limited the clinical translation of antibodies against SIRPα. Here, we report the development of humanized AB21 (hAB21), a pan-allelic anti-SIRPα antibody that binds human, cynomolgus monkey, and mouse SIRPα alleles with high affinity and blocks the interaction with CD47.


  • Organizational Affiliation

    ALX Oncology, Burlingame, CA, USA. tracy@tallactx.com.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Heavy chain of Fab 25 anti-SIRP-alpha antibodyA [auth H]212Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Light chain of Fab 25 anti-SIRP-alpha antibodyB [auth L]212Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Tyrosine-protein phosphatase non-receptor type substrate 1C [auth S]115Homo sapiensMutation(s): 0
Gene Names: SIRPABITMFRMYD1PTPNS1SHPS1SIRP
UniProt & NIH Common Fund Data Resources
Find proteins for P78324 (Homo sapiens)
Explore P78324
Go to UniProtKB:  P78324
PHAROS:  P78324
GTEx:  ENSG00000198053
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP78324
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.27 Å
  • R-Value Free: 0.282
  • R-Value Work: 0.234
  • R-Value Observed: 0.237
  • Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 189.16α = 90
b = 189.16β = 90
c = 78.4γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-12-16
    Type: Initial release
  • Version 1.1: 2023-10-18
    Changes: Data collection, Database references, Refinement description
