Biological Assembly 1

 3D View: Structure | 1D-3D View | Electron Density | Validation Report | Ligand Interaction

Global Symmetry: Cyclic - C2  (3D View)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 34.07 kDa
• Atom Count: 2704
• Modelled Residue Count: 299
• Deposited Residue Count: 306
• Unique protein chains: 1

7JR4

SARS-CoV-2 3CL protease with alternative conformation of the active site promoted by methylene-bridged cysteine and lysine residues

• PDB DOI: 10.2210/pdb7JR4/pdb

• Classification: HYDROLASE
• Organism(s): Severe acute respiratory syndrome coronavirus 2
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2020-08-11 Released: 2020-08-26
• Deposition Author(s): Nascimento, A.F.Z., de Oliveira, R.R., Zeri, A.C.M., Trivella, D.B.B.
• Funding Organization(s): FINEP

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.55 Å
• R-Value Free: 0.180
• R-Value Work: 0.153
• R-Value Observed: 0.154

Literature

SARS-CoV-2 3CL protease with alternative conformation of the active site promoted by methylene-bridged cysteine and lysine residues

Nascimento, A.F.Z., de Oliveira, R.R., Zeri, A.C.M., Trivella, D.B.B.

To be published.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
3C-like proteinase	A	306	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0  Gene Names: rep, 1a-1b EC: 3.4.22.69 (PDB Primary Data), 3.4.19.12 (UniProt), 3.4.22 (UniProt), 2.7.7.48 (UniProt), 3.6.4.12 (UniProt), 3.6.4.13 (UniProt), 3.1.13 (UniProt), 3.1 (UniProt), 2.1.1 (UniProt)
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1  Go to UniProtKB:  P0DTD1

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
DMS	B [auth A], C [auth A], D [auth A]	DIMETHYL SULFOXIDE C2 H6 O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MLZ	A	L-PEPTIDE LINKING	C7 H16 N2 O2		LYS

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.55 Å
• R-Value Free: 0.180
• R-Value Work: 0.153
• R-Value Observed: 0.154
• Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 97.153	α = 90
b = 82.353	β = 114.62
c = 51.59	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction

Structure Validation

Entry History & Funding Information

Deposition Data

• Deposited Date: 2020-08-11
• Released Date: 2020-08-26
Deposition Author(s): Nascimento, A.F.Z., de Oliveira, R.R., Zeri, A.C.M., Trivella, D.B.B.

---

Funding Organization	Location	Grant Number
FINEP	Brazil	01.20.0003.00

Revision History

• Version 1.0: 2020-08-26
  Type: Initial release
