7JJO | pdb_00007jjo

Structural Basis of the Activation of Heterotrimeric Gs-protein by Isoproterenol-bound Beta1-Adrenergic Receptor


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.60 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7JJO

This is version 1.2 of the entry. See complete history

Literature

Structural Basis of the Activation of Heterotrimeric Gs-Protein by Isoproterenol-Bound beta 1 -Adrenergic Receptor.

Su, M.Zhu, L.Zhang, Y.Paknejad, N.Dey, R.Huang, J.Lee, M.Y.Williams, D.Jordan, K.D.Eng, E.T.Ernst, O.P.Meyerson, J.R.Hite, R.K.Walz, T.Liu, W.Huang, X.Y.

(2020) Mol Cell 80: 59

  • DOI: https://doi.org/10.1016/j.molcel.2020.08.001
  • Primary Citation Related Structures:
    7JJO

  • PubMed Abstract:

    Cardiac disease remains the leading cause of morbidity and mortality worldwide. The β 1 -adrenergic receptor (β 1 -AR) is a major regulator of cardiac functions and is downregulated in the majority of heart failure cases. A key physiological process is the activation of heterotrimeric G-protein Gs by β 1 -ARs, leading to increased heart rate and contractility. Here, we use cryo-electron microscopy and functional studies to investigate the molecular mechanism by which β 1 -AR activates Gs. We find that the tilting of α5-helix breaks a hydrogen bond between the sidechain of His373 in the C-terminal α5-helix and the backbone carbonyl of Arg38 in the N-terminal αN-helix of Gα s . Together with the disruption of another interacting network involving Gln59 in the α1-helix, Ala352 in the β6-α5 loop, and Thr355 in the α5-helix, these conformational changes might lead to the deformation of the GDP-binding pocket. Our data provide molecular insights into the activation of G-proteins by G-protein-coupled receptors.


  • Organizational Affiliation
    • Department of Physiology and Biophysics, Weill Cornell Medical College of Cornell University, New York, NY 10065, USA.

Macromolecule Content

  • Total Structure Weight: 163.14 kDa
  • Atom Count: 7,892
  • Modeled Residue Count: 1,002
  • Deposited Residue Count: 1,440
  • Unique protein chains: 5

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1A [auth B]339Bos taurusMutation(s): 0
Gene Names: GNB1
UniProt
Find proteins for P62871 (Bos taurus)
Explore P62871
Go to UniProtKB:  P62871
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62871
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Nanobody 35B [auth N]138Lama glamaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Guanine nucleotide-binding protein G(s) subunit alpha isoforms shortC [auth A]384Bos taurusMutation(s): 0
Gene Names: GNASGNAS1
EC: 3.6.5
Membrane Entity: Yes
UniProt
Find proteins for P04896 (Bos taurus)
Explore P04896
Go to UniProtKB:  P04896
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04896
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2D [auth G]71Bos taurusMutation(s): 1
Gene Names: GNG2
Membrane Entity: Yes
UniProt
Find proteins for P63212 (Bos taurus)
Explore P63212
Go to UniProtKB:  P63212
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP63212
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
Beta1-Adrenergic ReceptorE [auth R]508Meleagris gallopavoMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P07700 (Meleagris gallopavo)
Explore P07700
Go to UniProtKB:  P07700
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07700
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
5FW
(Subject of Investigation/LOI)

Query on 5FW



Download:Ideal Coordinates CCD File
F [auth R]ISOPRENALINE
C11 H17 N O3
JWZZKOKVBUJMES-NSHDSACASA-N

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.60 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Heart, Lung, and Blood Institute (NIH/NHLBI)United StatesHL130478

Revision History  (Full details and data files)

  • Version 1.0: 2020-09-02
    Type: Initial release
  • Version 1.1: 2020-10-14
    Changes: Database references
  • Version 1.2: 2024-11-20
    Changes: Data collection, Database references, Structure summary
