7FCY

Crystal structure of M.tuberculosis imidazole glycerol phosphate dehydratase in complex with an inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free: 0.184
  • R-Value Work: 0.155

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Crystal structure of M.tuberculosis imidazole glycerol phosphate dehydratase in complex with an inhibitor

Tiwari, S.Pal, R.K.Biswal, B.K.

To be published.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Imidazoleglycerol-phosphate dehydratase210Mycobacterium tuberculosis H37RvMutation(s): 0
Gene Names: hisBRv1601MTCY336.03c
EC: 4.2.1.19
UniProt
Find proteins for P9WML9 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Explore P9WML9
Go to UniProtKB:  P9WML9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP9WML9
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
47Z (Subject of Investigation/LOI)
Query on 47Z

Download Ideal Coordinates CCD File
D [auth A](1S)-2-methyl-1-(2-methyl-1,2,4-triazol-3-yl)propan-1-amine
C7 H14 N4
LUTYSHHATVYMSC-LURJTMIESA-N
EDO
Query on EDO

Download Ideal Coordinates CCD File
E [auth A],
H [auth A]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
ACT
Query on ACT

Download Ideal Coordinates CCD File
G [auth A]ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
MN
Query on MN

Download Ideal Coordinates CCD File
B [auth A],
C [auth A]
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
CL
Query on CL

Download Ideal Coordinates CCD File
F [auth A]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free: 0.184
  • R-Value Work: 0.155
  • Space Group: P 4 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 113.116α = 90
b = 113.116β = 90
c = 113.116γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2022-07-20
    Type: Initial release
  • Version 1.1: 2023-11-29
    Changes: Data collection, Refinement description
