7EUU | pdb_00007euu

Crystal structures of 2-oxoglutarate dependent dioxygenase (CTB9) in complex with N-oxalylglycine and pre-cercosporin

PDB DOI: https://doi.org/10.2210/pdb7EUU/pdb

Classification: OXIDOREDUCTASE
Organism(s): Cercospora sojina
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2021-05-18 Released: 2022-05-25
Deposition Author(s): Hou, X.D., Liu, X.Z., Yuan, Z.B., Rao, Y.J.
Funding Organization(s): Other private

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free:
0.246 (Depositor), 0.244 (DCC)
R-Value Work:
0.207 (Depositor), 0.210 (DCC)
R-Value Observed:
0.211 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Molecular Basis of the Unusual Seven-Membered Methylenedioxy Bridge Formation Catalyzed by Fe(II)/alpha-KG-Dependent Oxygenase CTB9

Liu, X.Z., Yuan, Z.B., Su, H., Hou, X.D., Deng, Z.W., Xu, H.B., Guo, B.D., Yin, D., Sheng, X., Rao, Y.J.

(2022) ACS Catal 12: 3689-3699

DOI: https://doi.org/doi.org/10.1021/acscatal.1c04627

Macromolecule Content

Total Structure Weight: 78.79 kDa
Atom Count: 5,080
Modeled Residue Count: 576
Deposited Residue Count: 666
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
2-oxoglutarate (2-OG)-dependent dioxygenase	A, B	333	Cercospora sojina	Mutation(s): 0 EC: 1
UniProt
Find proteins for A0A2G5I8W0 (Cercospora beticola) Explore A0A2G5I8W0 Go to UniProtKB: A0A2G5I8W0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A2G5I8W0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
JD9 (Subject of Investigation/LOI) Query on JD9 Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain H [auth B] MOL2 format, chain E [auth A] MOL2 format, chain H [auth B] mmCIF format, chain E [auth A] mmCIF format, chain H [auth B]	E [auth A], H [auth B]	2,6,11-trimethoxy-4,7,9-tris(oxidanyl)-1,12-bis[(2R)-2-oxidanylpropyl]perylene-3,10-dione C₂₉ H₂₈ O₁₀ SZXDWEFJNLPCTA-GHMZBOCLSA-N		Interactions Focus chain E [auth A] Focus chain H [auth B] Interactions & Density Focus chain E [auth A] Focus chain H [auth B]
OGA Query on OGA Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain G [auth B] MOL2 format, chain D [auth A] MOL2 format, chain G [auth B] mmCIF format, chain D [auth A] mmCIF format, chain G [auth B]	D [auth A], G [auth B]	N-OXALYLGLYCINE C₄ H₅ N O₅ BIMZLRFONYSTPT-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain G [auth B] Interactions & Density Focus chain D [auth A] Focus chain G [auth B]
CU Query on CU Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain F [auth B] MOL2 format, chain C [auth A] MOL2 format, chain F [auth B] mmCIF format, chain C [auth A] mmCIF format, chain F [auth B]	C [auth A], F [auth B]	COPPER (II) ION Cu JPVYNHNXODAKFH-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain F [auth B] Interactions & Density Focus chain C [auth A] Focus chain F [auth B]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain I [auth B] SDF format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain J [auth B]	I [auth B], J [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain I [auth B] Focus chain J [auth B] Interactions & Density Focus chain I [auth B] Focus chain J [auth B]
