7ELN

Structure of Csy-AcrIF24-dsDNA

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.00 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history.


Literature

Insights into the inhibition of type I-F CRISPR-Cas system by a multifunctional anti-CRISPR protein AcrIF24.

Yang, L., Zhang, L., Yin, P., Ding, H., Xiao, Y., Zeng, J., Wang, W., Zhou, H., Wang, Q., Zhang, Y., Chen, Z., Yang, M., Feng, Y.

(2022) Nat Commun 13: 1931-1931

  • DOI: https://doi.org/10.1038/s41467-022-29581-1
  • Primary Citation of Related Structures:
    7DTR, 7ELM, 7ELN, 7WE6

  • PubMed Abstract:

    • CRISPR-Cas systems are prokaryotic adaptive immune systems and phages use anti-CRISPR proteins (Acrs) to counteract these systems. Here, we report the structures of AcrIF24 and its complex with the crRNA-guided surveillance (Csy) complex. The HTH motif of AcrIF24 can bind the Acr promoter region and repress its transcription, suggesting its role as an Aca gene in self-regulation ...

    CRISPR-Cas systems are prokaryotic adaptive immune systems and phages use anti-CRISPR proteins (Acrs) to counteract these systems. Here, we report the structures of AcrIF24 and its complex with the crRNA-guided surveillance (Csy) complex. The HTH motif of AcrIF24 can bind the Acr promoter region and repress its transcription, suggesting its role as an Aca gene in self-regulation. AcrIF24 forms a homodimer and further induces dimerization of the Csy complex. Apart from blocking the hybridization of target DNA to the crRNA, AcrIF24 also induces the binding of non-sequence-specific dsDNA to the Csy complex, similar to AcrIF9, although this binding seems to play a minor role in AcrIF24 inhibitory capacity. Further structural and biochemical studies of the Csy-AcrIF24-dsDNA complexes and of AcrIF24 mutants reveal that the HTH motif of AcrIF24 and the PAM recognition loop of the Csy complex are structural elements essential for this non-specific dsDNA binding. Moreover, AcrIF24 and AcrIF9 display distinct characteristics in inducing non-specific DNA binding. Together, our findings highlight a multifunctional Acr and suggest potential wide distribution of Acr-induced non-specific DNA binding.

    Organizational Affiliation:

    Beijing Advanced Innovation Center for Soft Matter Science and Engineering, Beijing Key Laboratory of Bioprocess, State Key Laboratory of Chemical Resource Engineering, College of Life Science and Technology, Beijing University of Chemical Technology, Beijing, 100029, China. fengyue@mail.buct.edu.cn.



Macromolecules

Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
CRISPR type I-F/YPEST-associated protein Csy2A [auth B],
I [auth L]		327Pseudomonas aeruginosaMutation(s): 0
Gene Names: csy2, ALP65_00953, EQH76_13810, NCTC13437_01526, PACL_0128
UniProt
Find proteins for Q02MM0 (Pseudomonas aeruginosa (strain UCBPP-PA14))
Explore Q02MM0
Go to UniProtKB:  Q02MM0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ02MM0
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
CRISPR-associated protein Csy3342Pseudomonas aeruginosaMutation(s): 0
Gene Names: IPC1505_30680, IPC36_28835
UniProt
Find proteins for Q02MM1 (Pseudomonas aeruginosa (strain UCBPP-PA14))
Explore Q02MM1
Go to UniProtKB:  Q02MM1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ02MM1
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
type I-F CRISPR-associated endoribonuclease Cas6/Csy4H [auth I],
P [auth S]		187Pseudomonas aeruginosaMutation(s): 0
EC: 3.1
UniProt
Find proteins for Q02MM2 (Pseudomonas aeruginosa (strain UCBPP-PA14))
Explore Q02MM2
Go to UniProtKB:  Q02MM2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ02MM2
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
AcrIF24Q [auth U],
R [auth V]		228Pseudomonas aeruginosaMutation(s): 0
Gene Names: IPC1505_27760, IPC1506_06140, IPC1507_17575, IPC30_18380, IPC31_22945
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetailsImage
Type I-F CRISPR-associated protein Csy1U [auth A],
X		434Pseudomonas aeruginosaMutation(s): 0
Gene Names:
UniProt
Find proteins for A0A3A8DDU9 (Pseudomonas aeruginosa)
Explore A0A3A8DDU9
Go to UniProtKB:  A0A3A8DDU9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A3A8DDU9
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:
(by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChainsLengthOrganismImage
RNA (60-MER)S [auth J],
T		60Pseudomonas aeruginosa
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:
(by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChainsLengthOrganismImage
54-MER DNAV [auth K],
Y		54Pseudomonas aeruginosa
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:
(by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChainsLengthOrganismImage
54-MER DNA
W, Z
54Pseudomonas aeruginosa
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.00 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Science Foundation (NSF, China)China31822012

Revision History  (Full details and data files)

  • Version 1.0: 2022-04-20
    Type: Initial release
  • Version 1.1: 2022-04-27
    Changes: Database references
