7DO1

Solution structure of a heteromolecular telomeric (3+1) G-quadruplex containing right loop progression

  • Classification: DNA
  • Organism(s): Homo sapiens
  • Mutation(s): No

  • Deposited: 2020-12-11 Released: 2021-09-29
  • Deposition Author(s): Fu, W.Q., Jing, H.T., Zhang, N.
  • Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 200
  • Conformers Submitted: 10
  • Selection Criteria: structures with the lowest energy

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Two coexisting pseudo-mirror heteromolecular telomeric G-quadruplexes in opposite loop progressions differentially recognized by a low equivalent of Thioflavin T.

Fu, W.Jing, H.Xu, X.Xu, S.Wang, T.Hu, W.Li, H.Zhang, N.

(2021) Nucleic Acids Res 49: 10717-10734

  • DOI: https://doi.org/10.1093/nar/gkab755
  • Primary Citation of Related Structures:
    7DO1

  • PubMed Abstract:

    The final 3'-terminal residue of the telomeric DNA G-overhang is inherently less precise. Here, we describe how alteration of the last 3'-terminal base affects the mutual recognition between two different G-rich oligomers of human telomeric DNA in the formation of heteromolecular G-quadruplexes (hetero-GQs). Associations between three- and single-repeat fragments of human telomeric DNA, target d(GGGTTAGGGTTAGGG) and probe d(TAGGGT), in Na+ solution yield two coexisting forms of (3 + 1) hybrid hetero-GQs: the kinetically favourable LLP-form (left loop progression) and the thermodynamically controlled RLP-form (right loop progression). However, only the adoption of a single LLP-form has been previously reported between the same probe d(TAGGGT) and a target variant d(GGGTTAGGGTTAGGGT) having one extra 3'-end thymine. Moreover, the flanking base alterations of short G-rich probe variants also significantly affect the loop progressions of hetero-GQs. Although seemingly two pseudo-mirror counter partners, the RLP-form exhibits a preference over the LLP-form to be recognized by a low equivalent of fluorescence dye thioflavin T (ThT). To a greater extent, ThT preferentially binds to RLP hetero-GQ than with the corresponding telomeric DNA duplex context or several other representative unimolecular GQs.


  • Organizational Affiliation

    High Magnetic Field Laboratory, Chinese Academy of Sciences, Hefei 230031, China.


Macromolecules

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains LengthOrganismImage
DNA (5'-D(*GP*GP*GP*TP*TP*AP*GP*GP*GP*TP*TP*AP*GP*GP*G)-3')15Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(*TP*TP*AP*GP*GP*G)-3')6Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 200
  • Conformers Submitted: 10
  • Selection Criteria: structures with the lowest energy

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)ChinaU1932157
National Natural Science Foundation of China (NSFC)China21372223
National Natural Science Foundation of China (NSFC)ChinaU1232145

Revision History  (Full details and data files)

  • Version 1.0: 2021-09-29
    Type: Initial release
  • Version 1.1: 2022-02-16
    Changes: Database references
  • Version 1.2: 2023-06-14
    Changes: Other
