7D36 | pdb_00007d36

Crystal Structure of BACE1 in complex with N-{3-[(3S)-1-amino-5-fluoro-3-methyl-3,4-dihydro-2,6-naphthyridin-3-yl]-4-fluorophenyl}-5-cyano-3-methylpyridine-2-carboxamide


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:
    0.265 (Depositor), 0.268 (DCC)
  • R-Value Work:
    0.213 (Depositor), 0.216 (DCC)
  • R-Value Observed:
    0.218 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7D36

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Balancing potency and basicity by incorporating fluoropyridine moieties: Discovery of a 1-amino-3,4-dihydro-2,6-naphthyridine BACE1 inhibitor that affords robust and sustained central A beta reduction.

Nakahara, K.Mitsuoka, Y.Kasuya, S.Yamamoto, T.Yamamoto, S.Ito, H.Kido, Y.Kusakabe, K.I.

(2021) Eur J Med Chem 216: 113270-113270

  • DOI: https://doi.org/10.1016/j.ejmech.2021.113270
  • Primary Citation Related Structures:
    7D36

  • PubMed Abstract:

    β-Site amyloid precursor protein cleaving enzyme 1 (BACE1) has been pursued as a prime target for the treatment of Alzheimer's disease (AD). In this report, we describe the discovery of BACE1 inhibitors with a 1-amino-3,4-dihydro-2,6-naphthyridine scaffold. Leveraging known inhibitors 2a and 2b, we designed the naphthyridine-based compounds by removing a structurally labile moiety and incorporating pyridine rings, which showed increased biochemical and cellular potency, along with reduced basicity on the amidine moiety. Introduction of a fluorine atom on the pyridine culminated in compound 11 which had improved cellular activity as well as further reduced basicity and demonstrated a robust and sustained cerebrospinal fluid (CSF) Aβ reduction in dog. The crystal structure of compound 11 bound to BACE1 confirmed van der Waals interactions between the fluorine on the pyridine and Tyr71 in the flap.


  • Organizational Affiliation
    • Discovery Research Laboratory for Core Therapeutic Areas, Shionogi Pharmaceutical Research Center, 1-1 Futaba-cho 3-chome, Toyonaka, Osaka, 561-0825, Japan. Electronic address: kenji.nakahara@shionogi.co.jp.

Macromolecule Content

  • Total Structure Weight: 47.61 kDa
  • Atom Count: 3,128
  • Modeled Residue Count: 378
  • Deposited Residue Count: 416
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Beta-secretase 1416Homo sapiensMutation(s): 0
Gene Names: BACE1BACEKIAA1149
EC: 3.4.23.46
UniProt & NIH Common Fund Data Resources
Find proteins for P56817 (Homo sapiens)
Explore P56817
Go to UniProtKB:  P56817
PHAROS:  P56817
GTEx:  ENSG00000186318
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP56817
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
GUC
(Subject of Investigation/LOI)

Query on GUC



Download:Ideal Coordinates CCD File
I [auth A]N-[3-[(3S)-1-azanyl-5-fluoranyl-3-methyl-4H-2,6-naphthyridin-3-yl]-4-fluoranyl-phenyl]-5-cyano-3-methyl-pyridine-2-carboxamide
C23 H18 F2 N6 O
UOHLPZVSOSMODJ-QHCPKHFHSA-N
IOD

Query on IOD



Download:Ideal Coordinates CCD File
B [auth A],
C [auth A],
D [auth A],
E [auth A]
IODIDE ION
I
XMBWDFGMSWQBCA-UHFFFAOYSA-M
GOL

Query on GOL



Download:Ideal Coordinates CCD File
F [auth A],
G [auth A],
H [auth A]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:  0.265 (Depositor), 0.268 (DCC)
  • R-Value Work:  0.213 (Depositor), 0.216 (DCC)
  • R-Value Observed: 0.218 (Depositor)
Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 102.531α = 90
b = 102.531β = 90
c = 170.115γ = 120
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data scaling
MOLREPphasing
REFMACrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-07-28
    Type: Initial release
  • Version 1.1: 2023-11-29
    Changes: Data collection, Database references, Refinement description
  • Version 1.2: 2024-11-13
    Changes: Structure summary
