7BVN

Crystal structure of glucose isomerase delivered in alginate

  • Classification: ISOMERASE
  • Organism(s): Streptomyces rubiginosus
  • Mutation(s): No

  • Deposited: 2020-04-11 Released: 2020-11-18
  • Deposition Author(s): Nam, K.H.
  • Funding Organization(s): National Research Foundation (NRF, Korea)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.226
  • R-Value Work: 0.192
  • R-Value Observed: 0.193

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Polysaccharide-Based Injection Matrix for Serial Crystallography.

Nam, K.H.

(2020) Int J Mol Sci 21

  • DOI: 10.3390/ijms21093332
  • Primary Citation of Related Structures:
    7BVM, 7BVN, 7BVL, 7BVO

  • PubMed Abstract:
  • Serial crystallography (SX) provides an opportunity to observe the molecular dynamics of macromolecular structures at room temperature via pump-probe studies. The delivery of crystals embedded in a viscous medium via an injector or syringe is widely performed in synchrotrons or X-ray free-electron laser facilities with low repetition rates ...

    Serial crystallography (SX) provides an opportunity to observe the molecular dynamics of macromolecular structures at room temperature via pump-probe studies. The delivery of crystals embedded in a viscous medium via an injector or syringe is widely performed in synchrotrons or X-ray free-electron laser facilities with low repetition rates. Various viscous media have been developed; however, there are cases in which the delivery material undesirably interacts chemically or biologically with specific protein samples, or changes the stability of the injection stream, depending on the crystallization solution. Therefore, continued discovery and characterization of new delivery media is necessary for expanding future SX applications. Here, the preparation and characterization of new polysaccharide (wheat starch (WS) and alginate)-based sample delivery media are introduced for SX. Crystals embedded in a WS or alginate injection medium showed a stable injection stream at a flow rate of < 200 nL/min and low-level X-ray background scattering similar to other hydrogels. Using these media, serial millisecond crystallography (SMX) was performed, and the room temperature crystal structures of glucose isomerase and lysozyme were determined at 1.9-2.0 Å resolutions. WS and alginate will allow an expanded application of sample delivery media in SX experiments.


    Organizational Affiliation

    Department of Life Science, Pohang University of Science and Technology, Pohang 37673, Korea.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Xylose isomeraseA388Streptomyces rubiginosusMutation(s): 0
Gene Names: xylA
EC: 5.3.1.5
UniProt
Find proteins for P24300 (Streptomyces rubiginosus)
Explore P24300
Go to UniProtKB:  P24300
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MG
Query on MG

Download Ideal Coordinates CCD File
B [auth A], C [auth A]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.226
  • R-Value Work: 0.192
  • R-Value Observed: 0.193
  • Space Group: I 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 94.09α = 90
b = 99.88β = 90
c = 103γ = 90
Software Package:
Software NamePurpose
HKL-2000data scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data

  • Deposited Date: 2020-04-11
  • Released Date: 2020-11-18
  • Deposition Author(s): Nam, K.H.

Funding OrganizationLocationGrant Number
National Research Foundation (NRF, Korea)Korea, Republic OfNRF-2017M3A9F6029736

Revision History  (Full details and data files)

  • Version 1.0: 2020-11-18
    Type: Initial release
