7AYW | pdb_00007ayw

Crystal structure of a shortened IpgC variant in complex with 2H-isoindol-1-amine

PDB DOI: https://doi.org/10.2210/pdb7AYW/pdb

Classification: CHAPERONE
Organism(s): Shigella flexneri
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2020-11-13 Released: 2021-11-24
Deposition Author(s): Gardonyi, M., Heine, A., Klebe, G.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.78 Å
R-Value Free:
0.228 (Depositor), 0.230 (DCC)
R-Value Work:
0.180 (Depositor), 0.183 (DCC)
R-Value Observed:
0.183 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7AYW

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of a shortened IpgC variant in complex with 2H-isoindol-1-amine

Gardonyi, M., Heine, A., Klebe, G.

To be published.

Macromolecule Content

Total Structure Weight: 33.35 kDa
Atom Count: 2,461
Modeled Residue Count: 281
Deposited Residue Count: 286
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Chaperone protein IpgC	A, B	143	Shigella flexneri	Mutation(s): 0 Gene Names: ipgC, ippI, CP0129
UniProt
Find proteins for P0A2U4 (Shigella flexneri) Explore P0A2U4 Go to UniProtKB: P0A2U4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0A2U4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
F05 Query on F05 Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain J [auth B] MOL2 format, chain C [auth A] MOL2 format, chain J [auth B] mmCIF format, chain C [auth A] mmCIF format, chain J [auth B]	C [auth A], J [auth B]	1H-isoindol-3-amine C₈ H₈ N₂ MTKKGHVQPVOXIL-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain J [auth B] Interactions & Density Focus chain C [auth A] Focus chain J [auth B]
PEG Query on PEG Download:Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]
DMS Query on DMS Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain M [auth B] MOL2 format, chain I [auth A] MOL2 format, chain M [auth B] mmCIF format, chain I [auth A] mmCIF format, chain M [auth B]	I [auth A], M [auth B]	DIMETHYL SULFOXIDE C₂ H₆ O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain M [auth B] Interactions & Density Focus chain I [auth A] Focus chain M [auth B]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain K [auth B] SDF format, chain L [auth B] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B]	D [auth A], E [auth A], F [auth A], K [auth B], L [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain K [auth B] Focus chain L [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain K [auth B] Focus chain L [auth B]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.78 Å
R-Value Free: 0.228 (Depositor), 0.230 (DCC)
R-Value Work: 0.180 (Depositor), 0.183 (DCC)
R-Value Observed: 0.183 (Depositor)

Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.791	α = 90
b = 56.791	β = 90
c = 162.092	γ = 120

Software Package:

Software Name	Purpose
XDS	data reduction
XDS	data scaling
PHASER	phasing
PHENIX	refinement
Coot	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2021-11-24

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2021-11-24
Type: Initial release
Version 1.1: 2024-01-31
Changes: Data collection, Refinement description
