7AYG

oxalyl-CoA decarboxylase from Methylorubrum extorquens with bound TPP and ADP


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.176
  • R-Value Observed: 0.177

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Engineering a Highly Efficient Carboligase for Synthetic One-Carbon Metabolism.

Nattermann, M.Burgener, S.Pfister, P.Chou, A.Schulz, L.Lee, S.H.Paczia, N.Zarzycki, J.Gonzalez, R.Erb, T.J.

(2021) ACS Catal 11: 5396-5404

  • DOI: https://doi.org/10.1021/acscatal.1c01237
  • Primary Citation of Related Structures:
    7AYG, 7B2E

  • PubMed Abstract:

    One of the biggest challenges to realize a circular carbon economy is the synthesis of complex carbon compounds from one-carbon (C1) building blocks. Since the natural solution space of C1-C1 condensations is limited to highly complex enzymes, the development of more simple and robust biocatalysts may facilitate the engineering of C1 assimilation routes. Thiamine diphosphate-dependent enzymes harbor great potential for this task, due to their ability to create C-C bonds. Here, we employed structure-guided iterative saturation mutagenesis to convert oxalyl-CoA decarboxylase (OXC) from Methylobacterium extorquens into a glycolyl-CoA synthase (GCS) that allows for the direct condensation of the two C1 units formyl-CoA and formaldehyde. A quadruple variant MeOXC4 showed a 100 000-fold switch between OXC and GCS activities, a 200-fold increase in the GCS activity compared to the wild type, and formaldehyde affinity that is comparable to natural formaldehyde-converting enzymes. Notably, MeOCX4 outcompetes all other natural and engineered enzymes for C1-C1 condensations by more than 40-fold in catalytic efficiency and is highly soluble in Escherichia coli . In addition to the increased GCS activity, MeOXC4 showed up to 300-fold higher activity than the wild type toward a broad range of carbonyl acceptor substrates. When applied in vivo, MeOXC4 enables the production of glycolate from formaldehyde, overcoming the current bottleneck of C1-C1 condensation in whole-cell bioconversions and paving the way toward synthetic C1 assimilation routes in vivo.


  • Organizational Affiliation

    Department of Biochemistry & Synthetic Metabolism, Max-Planck-Institute for Terrestrial Microbiology, Karl-von-Frisch-Str. 10, 35043 Marburg, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Putative oxalyl-CoA decarboxylase (Oxc, yfdU)
A, B, C, D, E
A, B, C, D, E, F, G, H
583Methylorubrum extorquens AM1Mutation(s): 0
Gene Names: MexAM1_META1p0990
EC: 4.1.1.8
UniProt
Find proteins for C5AX46 (Methylorubrum extorquens (strain ATCC 14718 / DSM 1338 / JCM 2805 / NCIMB 9133 / AM1))
Explore C5AX46
Go to UniProtKB:  C5AX46
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC5AX46
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ADP
Query on ADP

Download Ideal Coordinates CCD File
BA [auth G]
EA [auth H]
J [auth A]
M [auth B]
P [auth C]
BA [auth G],
EA [auth H],
J [auth A],
M [auth B],
P [auth C],
S [auth D],
V [auth E],
Y [auth F]
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
TPP
Query on TPP

Download Ideal Coordinates CCD File
AA [auth G]
DA [auth H]
I [auth A]
L [auth B]
O [auth C]
AA [auth G],
DA [auth H],
I [auth A],
L [auth B],
O [auth C],
R [auth D],
U [auth E],
X [auth F]
THIAMINE DIPHOSPHATE
C12 H19 N4 O7 P2 S
AYEKOFBPNLCAJY-UHFFFAOYSA-O
MG
Query on MG

Download Ideal Coordinates CCD File
CA [auth G]
FA [auth H]
K [auth A]
N [auth B]
Q [auth C]
CA [auth G],
FA [auth H],
K [auth A],
N [auth B],
Q [auth C],
T [auth D],
W [auth E],
Z [auth F]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.176
  • R-Value Observed: 0.177
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 160.176α = 90
b = 181.798β = 90
c = 202.366γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Federal Ministry for Education and ResearchGermanyFormatPlant
Department of Energy (DOE, United States)United StatesDE-EE0008499

Revision History  (Full details and data files)

  • Version 1.0: 2021-04-28
    Type: Initial release
  • Version 1.1: 2021-09-29
    Changes: Data collection, Database references
  • Version 1.2: 2021-10-13
    Changes: Data collection, Database references
  • Version 1.3: 2024-01-31
    Changes: Data collection, Refinement description
