7AQW

Cryo-EM structure of Arabidopsis thaliana Complex-I (membrane tip)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.17 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

A ferredoxin bridge connects the two arms of plant mitochondrial complex I.

Klusch, N.Senkler, J.Yildiz, O.Kuhlbrandt, W.Braun, H.P.

(2021) Plant Cell 33: 2072-2091

  • DOI: https://doi.org/10.1093/plcell/koab092
  • Primary Citation of Related Structures:
    7AQQ, 7AQR, 7AQW, 7AR7, 7AR8, 7AR9, 7ARB, 7ARC, 7ARD

  • PubMed Abstract:

    Mitochondrial complex I is the main site for electron transfer to the respiratory chain and generates much of the proton gradient across the inner mitochondrial membrane. Complex I is composed of two arms, which form a conserved L-shape. We report the structures of the intact, 47-subunit mitochondrial complex I from Arabidopsis thaliana and the 51-subunit complex I from the green alga Polytomella sp., both at around 2.9 Å resolution. In both complexes, a heterotrimeric γ-carbonic anhydrase domain is attached to the membrane arm on the matrix side. Two states are resolved in A. thaliana complex I, with different angles between the two arms and different conformations of the ND1 (NADH dehydrogenase subunit 1) loop near the quinol binding site. The angle appears to depend on a bridge domain, which links the peripheral arm to the membrane arm and includes an unusual ferredoxin. We propose that the bridge domain participates in regulating the activity of plant complex I.


  • Organizational Affiliation

    Department of Structural Biology, Max-Planck-Institute of Biophysics, Frankfurt 60438, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-ubiquinone oxidoreductase chain 5A [auth L]669Arabidopsis thalianaMutation(s): 0
EC: 7.1.1.2
Membrane Entity: Yes
UniProt
Find proteins for P29388 (Arabidopsis thaliana)
Explore P29388
Go to UniProtKB:  P29388
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP29388
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
NADH-ubiquinone oxidoreductase chain 4B [auth M]495Arabidopsis thalianaMutation(s): 0
EC: 7.1.1.2
Membrane Entity: Yes
UniProt
Find proteins for P93313 (Arabidopsis thaliana)
Explore P93313
Go to UniProtKB:  P93313
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP93313
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Acyl carrier protein 1, mitochondrialC [auth T]122Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P53665 (Arabidopsis thaliana)
Explore P53665
Go to UniProtKB:  P53665
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53665
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Transmembrane proteinD [auth c]88Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q8VZT9 (Arabidopsis thaliana)
Explore Q8VZT9
Go to UniProtKB:  Q8VZT9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8VZT9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
ESSS subunit of NADH:ubiquinone oxidoreductase (Complex I) proteinE [auth g]114Arabidopsis thalianaMutation(s): 0
UniProt
Find proteins for Q9SLC8 (Arabidopsis thaliana)
Explore Q9SLC8
Go to UniProtKB:  Q9SLC8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9SLC8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
P1F [auth i]98Arabidopsis thalianaMutation(s): 0
UniProt
Find proteins for Q9FYF8 (Arabidopsis thaliana)
Explore Q9FYF8
Go to UniProtKB:  Q9FYF8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9FYF8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] 1 beta subcomplex subunit 2G [auth j]69Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q8LDK3 (Arabidopsis thaliana)
Explore Q8LDK3
Go to UniProtKB:  Q8LDK3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8LDK3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] 1 beta subcomplex subunit 3-AH [auth k]72Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for O64725 (Arabidopsis thaliana)
Explore O64725
Go to UniProtKB:  O64725
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO64725
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] 1 beta subcomplex subunit 8, mitochondrialI [auth l]125Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q9FGK0 (Arabidopsis thaliana)
Explore Q9FGK0
Go to UniProtKB:  Q9FGK0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9FGK0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
B15 -- 1 beta subcomplex subunit 4J [auth m]71Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q9SIQ8 (Arabidopsis thaliana)
Explore Q9SIQ8
Go to UniProtKB:  Q9SIQ8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9SIQ8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] 1 beta subcomplex subunit 9K [auth n]117Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q945M1 (Arabidopsis thaliana)
Explore Q945M1
Go to UniProtKB:  Q945M1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ945M1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] 1 beta subcomplex subunit 7L [auth o]103Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q9SKC9 (Arabidopsis thaliana)
Explore Q9SKC9
Go to UniProtKB:  Q9SKC9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9SKC9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
NADH dehydrogenase [ubiquinone] 1 beta subcomplex subunit 10-BM [auth p]106Arabidopsis thalianaMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q94C12 (Arabidopsis thaliana)
Explore Q94C12
Go to UniProtKB:  Q94C12
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ94C12
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PC7
Query on PC7

Download Ideal Coordinates CCD File
O [auth c](7S)-4-HYDROXY-N,N,N-TRIMETHYL-9-OXO-7-[(PALMITOYLOXY)METHYL]-3,5,8-TRIOXA-4-PHOSPHAHEXACOSAN-1-AMINIUM 4-OXIDE
C42 H85 N O8 P
PZNPLUBHRSSFHT-FAIXQHPJSA-O
PTY
Query on PTY

Download Ideal Coordinates CCD File
N [auth M]PHOSPHATIDYLETHANOLAMINE
C40 H80 N O8 P
NJGIRBISCGPRPF-KXQOOQHDSA-N
8Q1
Query on 8Q1

Download Ideal Coordinates CCD File
P [auth n]S-[2-({N-[(2R)-2-hydroxy-3,3-dimethyl-4-(phosphonooxy)butanoyl]-beta-alanyl}amino)ethyl] dodecanethioate
C23 H45 N2 O8 P S
MVHUOSAYFQKAMT-NRFANRHFSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.17 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Max Planck SocietyGermany--

Revision History  (Full details and data files)

  • Version 1.0: 2021-12-08
    Type: Initial release
