CO-bound sperm whale myoglobin measured by serial femtosecond crystallography

Experimental Data Snapshot

  • Resolution: 1.75 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.168
  • R-Value Observed: 0.172

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history


Serial femtosecond and serial synchrotron crystallography can yield data of equivalent quality: A systematic comparison.

Mehrabi, P.Bucker, R.Bourenkov, G.Ginn, H.M.von Stetten, D.Muller-Werkmeister, H.M.Kuo, A.Morizumi, T.Eger, B.T.Ou, W.L.Oghbaey, S.Sarracini, A.Besaw, J.E.Pare-Labrosse, O.Meier, S.Schikora, H.Tellkamp, F.Marx, A.Sherrell, D.A.Axford, D.Owen, R.L.Ernst, O.P.Pai, E.F.Schulz, E.C.Miller, R.J.D.

(2021) Sci Adv 7

  • DOI: https://doi.org/10.1126/sciadv.abf1380
  • Primary Citation of Related Structures:
    7A42, 7A43, 7A44, 7A45

  • PubMed Abstract:

    For the two proteins myoglobin and fluoroacetate dehalogenase, we present a systematic comparison of crystallographic diffraction data collected by serial femtosecond (SFX) and serial synchrotron crystallography (SSX). To maximize comparability, we used the same batch of micron-sized crystals, the same sample delivery device, and the same data analysis software. Overall figures of merit indicate that the data of both radiation sources are of equivalent quality. For both proteins, reasonable data statistics can be obtained with approximately 5000 room-temperature diffraction images irrespective of the radiation source. The direct comparability of SSX and SFX data indicates that the quality of diffraction data obtained from these samples is linked to the properties of the crystals rather than to the radiation source. Therefore, for other systems with similar properties, time-resolved experiments can be conducted at the radiation source that best matches the desired time resolution.

  • Organizational Affiliation

    Department for Atomically Resolved Dynamics, Max Planck Institute for the Structure and Dynamics of Matter, Luruper Chaussee 149, 22761 Hamburg, Germany. pedram.mehrabi@mpsd.mpg.de eike.schulz@mpsd.mpg.de.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Myoglobin154Physeter catodonMutation(s): 0
Gene Names: MB
Find proteins for P02185 (Physeter macrocephalus)
Explore P02185
Go to UniProtKB:  P02185
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02185
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.75 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.168
  • R-Value Observed: 0.172
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 37.9α = 90
b = 47.9β = 90
c = 83.5γ = 90
Software Package:
Software NamePurpose
CrystFELdata reduction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-04-07
    Type: Initial release
  • Version 1.1: 2024-01-31
    Changes: Data collection, Database references, Refinement description
