6ZJI | pdb_00006zji

Cryo-EM structure of wild-type KatG from M. tuberculosis

PDB DOI: https://doi.org/10.2210/pdb6ZJI/pdb
EM Map EMD-11234: EMDB EMDataResource

Classification: METAL BINDING PROTEIN
Organism(s): Mycobacterium tuberculosis
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2020-06-29 Released: 2021-07-07
Deposition Author(s): Blundell, T.L., Chaplin, A.K., Munir, A.
Funding Organization(s): Bill & Melinda Gates Foundation

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.70 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6ZJI

This is version 1.1 of the entry. See complete history.

Literature

Cryo-EM as a tool to study KatG from Mycobacterium tuberculosis

Blundell, T.L., Chaplin, A.K., Munir, A.

To be published.

Macromolecule Content

Total Structure Weight: 162.61 kDa
Atom Count: 10,791
Modeled Residue Count: 1,397
Deposited Residue Count: 1,480
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Catalase-peroxidase	A [auth AP1], B [auth BP1]	740	Mycobacterium tuberculosis	Mutation(s): 0 Gene Names: katG, AYJ03_010035, ERS007661_00994, ERS013471_02729, ERS024276_01596, ERS075361_01376, ERS094182_01139, F6W99_00474, FRD82_12135 EC: 1.11.1.21
UniProt
Find proteins for P9WIE5 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)) Explore P9WIE5 Go to UniProtKB: P9WIE5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P9WIE5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
HEM (Subject of Investigation/LOI) Query on HEM Download:Ideal Coordinates CCD File SDF format, chain C [auth AP1] SDF format, chain D [auth BP1] MOL2 format, chain C [auth AP1] MOL2 format, chain D [auth BP1] mmCIF format, chain C [auth AP1] mmCIF format, chain D [auth BP1]	C [auth AP1], D [auth BP1]	PROTOPORPHYRIN IX CONTAINING FE C₃₄ H₃₂ Fe N₄ O₄ KABFMIBPWCXCRK-RGGAHWMASA-L		Interactions Focus chain C [auth AP1] Focus chain D [auth BP1] Interactions & Density Focus chain C [auth AP1] Focus chain D [auth BP1]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.70 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2021-07-07

Deposition Author(s):

Funding Organization	Location	Grant Number
Bill & Melinda Gates Foundation	United Kingdom	RG 86546

Revision History (Full details and data files)

Version 1.0: 2021-07-07
Type: Initial release
Version 1.1: 2024-05-01
Changes: Data collection, Database references, Refinement description
