6XD2

Porcine pepsin in complex with darunavir

PDB DOI: https://doi.org/10.2210/pdb6XD2/pdb

Classification: HYDROLASE/INHIBITOR
Organism(s): Sus scrofa
Mutation(s): No

Deposited: 2020-06-09 Released: 2021-06-16
Deposition Author(s): Vuksanovic, N., Silvaggi, N.R.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.198
R-Value Work: 0.163
R-Value Observed: 0.165

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Porcine pepsin in complex with darunavir

Vuksanovic, N., Silvaggi, N.R.

To be published.

Macromolecule Content

Total Structure Weight: 35.14 kDa
Atom Count: 2,809
Modelled Residue Count: 323
Deposited Residue Count: 326
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Pepsin A	A	326	Sus scrofa	Mutation(s): 0 EC: 3.4.23.1
UniProt
Find proteins for P00791 (Sus scrofa) Explore P00791 Go to UniProtKB: P00791
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P00791
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
017 (Subject of Investigation/LOI) Query on 017 Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	(3R,3AS,6AR)-HEXAHYDROFURO[2,3-B]FURAN-3-YL(1S,2R)-3-[[(4-AMINOPHENYL)SULFONYL](ISOBUTYL)AMINO]-1-BENZYL-2-HYDROXYPROPYLCARBAMATE C₂₇ H₃₇ N₃ O₇ S CJBJHOAVZSMMDJ-HEXNFIEUSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
SEP Query on SEP	A	L-PEPTIDE LINKING	C₃ H₈ N O₆ P		SER

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.198
R-Value Work: 0.163
R-Value Observed: 0.165
Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 66.245	α = 90
b = 66.245	β = 90
c = 290.049	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2021-06-16

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2021-06-16
Type: Initial release
Version 1.1: 2023-10-18
Changes: Data collection, Database references, Refinement description
