6W2X

CryoEM Structure of Inactive GABAB Heterodimer

PDB DOI: https://doi.org/10.2210/pdb6W2X/pdb
EM Map EMD-21533: EMDB EMDataResource

Classification: SIGNALING PROTEIN
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): No
Membrane Protein: Yes OPMPDBTMMemProtMDmpstruc

Deposited: 2020-03-08 Released: 2020-07-01
Deposition Author(s): Papasergi-Scott, M.M., Robertson, M.J., Skiniotis, G.
Funding Organization(s): National Institutes of Health/National Institute of Neurological Disorders and Stroke (NIH/NINDS)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.60 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 2.1 of the entry. See complete history.

Macromolecule Content

Total Structure Weight: 200.18 kDa
Atom Count: 9,860
Modelled Residue Count: 1,345
Deposited Residue Count: 1,737
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Gamma-aminobutyric acid type B receptor subunit 1	A	829	Homo sapiens	Mutation(s): 0 Gene Names: GABBR1, GPRC3A Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UBS5 (Homo sapiens) Explore Q9UBS5 Go to UniProtKB: Q9UBS5
PHAROS: Q9UBS5 GTEx: ENSG00000204681
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9UBS5
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Gamma-aminobutyric acid type B receptor subunit 2	B	908	Homo sapiens	Mutation(s): 0 Gene Names: GABBR2, GPR51, GPRC3B Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for O75899 (Homo sapiens) Explore O75899 Go to UniProtKB: O75899
PHAROS: O75899 GTEx: ENSG00000136928
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O75899
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C, D	2		N-Glycosylation	Interactions Focus chain C Focus chain D Interactions & Density Focus chain C Focus chain D
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
L9Q Query on L9Q Download Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain J [auth B] MOL2 format, chain G [auth A] MOL2 format, chain J [auth B]	G [auth A], J [auth B]	(1S)-2-{[(S)-(2-aminoethoxy)(hydroxy)phosphoryl]oxy}-1-[(octadecanoyloxy)methyl]ethyl (9Z)-octadec-9-enoate C₄₁ H₈₀ N O₈ P JQKOHRZNEOQNJE-VYCVAHKRSA-N		Interactions Focus chain G [auth A] Focus chain J [auth B] Interactions & Density Focus chain G [auth A] Focus chain J [auth B]
SGG Query on SGG Download Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A]	H [auth A]	[(2~{S})-3-[[(1~{S})-1-(3,4-dichlorophenyl)ethyl]amino]-2-oxidanyl-propyl]-(phenylmethyl)phosphinic acid C₁₈ H₂₂ Cl₂ N O₃ P ZODSPDOOCZZEIM-BBRMVZONSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]
NAG Query on NAG Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A]	E [auth A], F [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Interactions & Density Focus chain E [auth A] Focus chain F [auth A]
MG Query on MG Download Ideal Coordinates CCD File SDF format, chain I [auth A] MOL2 format, chain I [auth A]	I [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Interactions & Density Focus chain I [auth A]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.60 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	RELION	3.1

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2020-07-01

Deposition Author(s):

Papasergi-Scott, M.M.

Robertson, M.J.

Skiniotis, G.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of Neurological Disorders and Stroke (NIH/NINDS)	United States	1R01NS092695-01

Revision History (Full details and data files)

Version 1.0: 2020-07-01
Type: Initial release
Version 1.1: 2020-07-08
Changes: Database references
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
Version 2.1: 2020-08-26
Changes: Database references, Structure summary
