6VKA | pdb_00006vka

HIV Integrase Core domain (IN) in complex with dimer-spanning ligand

PDB DOI: https://doi.org/10.2210/pdb6VKA/pdb

Classification: TRANSFERASE
Organism(s): Human immunodeficiency virus 1
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2020-01-19 Released: 2021-01-20
Deposition Author(s): Gorman, M.A., Parker, M.W.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.86 Å
R-Value Free:
0.212 (Depositor), 0.210 (DCC)
R-Value Work:
0.145 (Depositor), 0.150 (DCC)
R-Value Observed:
0.163 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

HIV Integrase core domain (IN) in complex with dimeric spanning inhibitor

Scanlon, M., Gorman, M.A.

To be published.

Macromolecule Content

Total Structure Weight: 38.51 kDa
Atom Count: 2,408
Modeled Residue Count: 284
Deposited Residue Count: 330
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Integrase	A, B	165	Human immunodeficiency virus 1	Mutation(s): 5 Gene Names: pol EC: 2.7.7
UniProt
Find proteins for F2WR39 (Human immunodeficiency virus type 1) Explore F2WR39 Go to UniProtKB: F2WR39
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F2WR39
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
QZV (Subject of Investigation/LOI) Query on QZV Download Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	2,2'-{ethane-1,2-diylbis[oxyethane-2,1-diylcarbamoyl-4,1-phenyleneethyne-2,1-diyl(5-methyl-1-benzofuran-2,3-diyl)]}diacetic acid C₄₆ H₄₀ N₂ O₁₀ PWEZNMFJKKNKMN-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
IOD Query on IOD Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain K [auth A] SDF format, chain L [auth B] SDF format, chain M [auth B] SDF format, chain S [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] MOL2 format, chain S [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B] mmCIF format, chain S [auth B]	C [auth A] D [auth A] K [auth A] L [auth B] M [auth B] C [auth A], D [auth A], K [auth A], L [auth B], M [auth B], S [auth B]	IODIDE ION I XMBWDFGMSWQBCA-UHFFFAOYSA-M		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain K [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain S [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain K [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain S [auth B]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain N [auth B] SDF format, chain O [auth B] SDF format, chain P [auth B] SDF format, chain Q [auth B] SDF format, chain R [auth B] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] MOL2 format, chain P [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B] mmCIF format, chain P [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B]	F [auth A] G [auth A] H [auth A] I [auth A] J [auth A] F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], N [auth B], O [auth B], P [auth B], Q [auth B], R [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B]
