6VGI

Crystal Structures of FLAP bound to MK-866

• PDB DOI: https://doi.org/10.2210/pdb6VGI/pdb

• Classification: MEMBRANE PROTEIN
• Organism(s): Homo sapiens
• Expression System: Spodoptera frugiperda
• Mutation(s): No
• Membrane Protein: Yes  PDBTMMemProtMDmpstruc


• Deposited: 2020-01-08 Released: 2020-12-02
• Deposition Author(s): Ho, J.D., Lee, M.R., Rauch, C.T., Aznavour, K., Park, J.S., Luz, J.G., Antonysamy, S., Condon, B., Maletic, M., Zhang, A., Hickey, M.J., Hughes, N.E., Chandrasekhar, S., Sloan, A.V., Gooding, K., Harvey, A., Yu, X.P., Kahl, S.D., Norman, B.H.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.61 Å
• R-Value Free: 0.276
• R-Value Work: 0.259
• R-Value Observed: 0.259

Literature

Structure-based, multi-targeted drug discovery approach to eicosanoid inhibition: Dual inhibitors of mPGES-1 and 5-lipoxygenase activating protein (FLAP).

Ho, J.D., Lee, M.R., Rauch, C.T., Aznavour, K., Park, J.S., Luz, J.G., Antonysamy, S., Condon, B., Maletic, M., Zhang, A., Hickey, M.J., Hughes, N.E., Chandrasekhar, S., Sloan, A.V., Gooding, K., Harvey, A., Yu, X.P., Kahl, S.D., Norman, B.H.

(2020) Biochim Biophys Acta Gen Subj 1865: 129800-129800

• PubMed: 33246032
• DOI: https://doi.org/10.1016/j.bbagen.2020.129800
• Primary Citation of Related Structures:
  6VGC, 6VGI, 6VL4


• PubMed Abstract:


  Due to the importance of both prostaglandins (PGs) and leukotrienes (LTs) as pro-inflammatory mediators, and the potential for eicosanoid shunting in the presence of pathway target inhibitors, we have investigated an approach to inhibiting the formation of both PGs and LTs as part of a multi-targeted drug discovery effort.

---

Organizational Affiliation:

Lilly Biotechnology Center, San Diego, CA 92121, USA. Electronic address: [e-mail].

Biological Assembly 1

Global Symmetry: Cyclic - C3  (Explore in 3D)
Global Stoichiometry: Homo 3-mer - A3

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Cyclic - C3  (Explore in 3D)
Global Stoichiometry: Homo 3-mer - A3

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 119.28 kDa
• Atom Count: 7,147
• Modelled Residue Count: 870
• Deposited Residue Count: 1,026
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
5-lipoxygenase-activating protein	A, B, C, D, E, F	171	Homo sapiens	Mutation(s): 0  Gene Names: ALOX5AP, FLAP Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P20292 (Homo sapiens) Explore P20292  Go to UniProtKB:  P20292
PHAROS:  P20292 GTEx:  ENSG00000132965

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
QY7 (Subject of Investigation/LOI)	G [auth A], I [auth B], J [auth B], L [auth C], N [auth E], P [auth F]	3-[3-(tert-butylsulfanyl)-1-[(4-chlorophenyl)methyl]-5-(propan-2-yl)-1H-indol-2-yl]-2,2-dimethylpropanoic acid C27 H34 Cl N O2 S QAOAOVKBIIKRNL-UHFFFAOYSA-N
SO4	H [auth A], K [auth B], M [auth C], O [auth E], Q [auth F]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.61 Å
• R-Value Free: 0.276
• R-Value Work: 0.259
• R-Value Observed: 0.259
• Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 214.418	α = 90
b = 66.297	β = 101.53
c = 109.43	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
MOSFLM	data reduction
SCALA	data scaling
PHASER	phasing

Structure Validation

Currently 6VGI does not have a validation slider image.

Entry History

Deposition Data

• Released Date: 2020-12-02
Deposition Author(s): Ho, J.D., Lee, M.R., Rauch, C.T., Aznavour, K., Park, J.S., Luz, J.G., Antonysamy, S., Condon, B., Maletic, M., Zhang, A., Hickey, M.J., Hughes, N.E., Chandrasekhar, S., Sloan, A.V., Gooding, K., Harvey, A., Yu, X.P., Kahl, S.D., Norman, B.H.

Revision History

• Version 1.0: 2020-12-02
  Type: Initial release

• Version 1.1: 2020-12-09
  Changes: Database references
• Version 1.2: 2020-12-16
  Changes: Database references
• Version 1.3: 2023-10-11
  Changes: Data collection, Database references, Refinement description
