6VA5 | pdb_00006va5

Tudor Domain of Tumor suppressor p53BP1 with MFP-4184

PDB DOI: https://doi.org/10.2210/pdb6VA5/pdb

Classification: TRANSCRIPTION
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2019-12-16 Released: 2020-04-29
Deposition Author(s): Zeng, H., Dong, A., Headey, S., Gunzburg, M., Doak, B., James, L.I., Bountra, C., Arrowsmith, C.H., Edwards, A.M., Brown, P.J., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.28 Å
R-Value Free:
0.185 (Depositor), 0.195 (DCC)
R-Value Work:
0.174 (Depositor), 0.181 (DCC)
R-Value Observed:
0.174 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Tudor Domain of Tumor suppressor p53BP1 with MFP-4184

Zeng, H., Dong, A., Headey, S., Gunzburg, M., Doak, B., James, L.I., Bountra, C., Arrowsmith, C.H., Edwards, A.M., Brown, P.J., Structural Genomics Consortium (SGC)

To be published.

Macromolecule Content

Total Structure Weight: 14.79 kDa
Atom Count: 1,239
Modeled Residue Count: 123
Deposited Residue Count: 125
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
TP53-binding protein 1	A	125	Homo sapiens	Mutation(s): 0 Gene Names: TP53BP1
UniProt & NIH Common Fund Data Resources
Find proteins for Q12888 (Homo sapiens) Explore Q12888 Go to UniProtKB: Q12888
PHAROS: Q12888 GTEx: ENSG00000067369
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q12888
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
QSS (Subject of Investigation/LOI) Query on QSS Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	2-(4-methylpiperazin-1-yl)aniline C₁₁ H₁₇ N₃ INWHDRNGZMHXEZ-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain E [auth A]	D [auth A], E [auth A], F [auth A], G [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
UNX Query on UNX Download Ideal Coordinates CCD File SDF format, chain J [auth A] SDF format, chain I [auth A] SDF format, chain H [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A]	H [auth A], I [auth A], J [auth A]	UNKNOWN ATOM OR ION X		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A]
